4–14 Maintenance and Service Guide
Removal and replacement procedures
Remove the WLAN module:
Ä
CAUTION: To prevent an unresponsive system, replace the wireless module only with a wireless module authorized for use in
the computer by the governmental agency that regulates wireless devices in your country or region. If you replace the module
and then receive a warning message, remove the module to restore computer functionality, and then contact technical support
through Help and Support.
1. Position the computer with the front toward you.
2. Loosen the two Phillips PM2.0×6.0 captive screws 1 that secure the memory/wireless module compartment
cover to the computer.
3. Lift the left side of the cover 2 to detach it from the computer.
4. Remove the memory/wireless module compartment cover 3. The memory/wireless module compartment
cover is included in the Plastics Kit, spare part number 577211-001.
