Item Description Spare part number
For use in only Russia and the People's Republic of China:
●
For use with ATI Mobility Radeon HD 530v discrete graphics and 33.8-cm (13.3-in)
displays
614962-001
●
For use with ATI Mobility Radeon HD 5470 discrete graphics and 33.8-cm (13.3-in)
displays
628490-001
●
For use with ATI Mobility Radeon HD 6370 discrete graphics and 33.8-cm (13.3-in)
displays
628620-001
●
For use with UMA graphics subsystem and 33.8-cm (13.3-in) displays 614963-001
(19) Power connector board with cable 599517-001
(20) RJ11 (modem) cable (see Cable kit)
(21) Speakers
● For use with 33.8-cm (13.3-in) displays 599566-001
●
For use with 35.6-cm (14.0-in) displays 605559-001
(22) USB connector board and cable 599524-001
(23) ExpressCard slot bezel (included in Plastics kit, see
Plastics Kit on page 30)
(24) Base enclosure
For use in computer models with 33.8-cm (13.3-in) displays 599514-001
For use in computer models with 35.6-cm (14.0-in) displays 599515-001
(25) Battery
9-cell, 93-Wh (2.8Ah) Li-ion 593573-001
6-cell, 47-Wh (2.2Ah) Li-ion 593572-001
(26) Hard drive (includes hard drive bracket)
750-GB, 5400-rpm 634250-001
640-GB, 5400-rpm 631160-001
500-GB, 7200-rpm 634919-001
320-GB, 7200-rpm 603783-001
250-GB, 7200-rpm 599541-001
Hard Drive Hardware Kit (not illustrated) 630889-001
(27) SIM (provided by your wireless vendor for use with WWAN option)
(28) Optical drive (includes bezel)
Blu-ray Disc ROM Drive with SuperMulti DVD±R/RW Double-Layer 599538-001
DVD±RW SuperMulti Double-Layer Drive with LightScribe 599540-001
DVD ROM Drive 599539-001
Battery Latch Kit (not illustrated) 657098-001
Optical drive connector for use in 35.6-cm (14.0-in) models (not illustrated) 632213-001
Computer major components 27
