Item Description Spare part number
(2) Webcam module 617666-001
(3) Display panel (also included with display assembly; see
Computer major components
on page 22)
●
33.8-cm (13.3-in), HD, BrightView 588160-001
● 35.6-cm (14.0-in), HD, BrightView 592144-001
●
33.8-cm (13.3-in), HD, Anti-Glare 623175-001
●
35.6-cm (14.0-in), HD, Anti-Glare 623176-001
(4) Display hinge kit
●
Display hinge and panel bracket (left and right) for 33.8-cm (13.3-in) displays 599536-001
●
Display hinge and panel bracket (left and right) for 35.6-cm (14.0-in) displays 599537-001
(5) Display cable (includes microphone and, on select models, webcam connector)
●
Display cable for 33.8-cm (13.3-in) displays with webcam 599534-001
●
Display cable for 35.6-cm (14.0-in) displays with webcam 605558-001
● Display cable for 33.8-cm (13.3-in) displays without webcam 605557-001
●
Display cable for 35.6-cm (14.0-in) displays without webcam 599535-001
●
Display cable for 33.8-cm (13.3-in) displays with webcam without WWAN 616070-001
(6) WLAN antennas and cables (included with back cover)
(7) WWAN antennas and cables (included with back covers used with WWAN option)
(8) Display back cover
For use on black models:
●
For 33.8-cm (13.3-in) displays without WWAN 599526-001
●
For 35.6-cm (14.0-in) displays without WWAN 599527-001
● For 35.6-cm (14.0-in) displays with webcam and without WWAN 605556-001
●
For 33.8-cm (13.3-in) displays with webcam and without WWAN 607094-001
For use on red models:
● For 33.8-cm (13.3-in) displays without WWAN 607643-001
●
For 33.8-cm (13.3-in) displays with webcam and without WWAN 607644-001
●
For 33.8-cm (14.0-in) displays without WWAN 607645-001
● For 35.6-cm (14.0-in) displays with webcam and without WWAN 607646-001
For use on champagne models:
●
For 33.8-cm (13.3-in) displays without WWAN 625698-001
● For 33.8-cm (13.3-in) displays with webcam and without WWAN 625699-001
Display assembly components 29
