HP ProBook 4330s Quickspecs

Chipset Mobile Intel HM65 Express Chipset
Graphics Models with integrated graphics (not an option on HP 4730s):
Intel HD Graphics 3000
Microsoft DirectX 10.1 (Shader Model 4.1) and OpenGL 3.0 capable
NOTE: Intel HD Graphics for configurations with Celeron processor
Models with discrete graphics*:
AMD Radeon™ HD 6490M with 512 MB or 1 GB dedicated GDDR5 video memory
Microsoft DirectX 11 (Shader Model 5.0) and OpenGL 4.0 capable
* AMD Dynamic Switchable Graphics technology switches automatically between the Intel integrated
graphics and the AMD Radeon discrete graphics to stretch battery life when running typical productivity
applications or to enable discrete graphics when running demanding applications. NOTE: This feature
requires Windows 7 Professional, Home Premium, and/or Home Basic OS. Full enablement of all discrete
graphics video and display features may not be supported on all applications (e.g., OpenGL applications
will run on the integrated graphics).
Display Internal HP ProBook 4330s:
13.3-inch diagonal LED-backlit HD anti-glare (1366 x 768 resolution)
13.3-inch diagonal LED-backlit HD BrightView (1366 x 768 resolution)
HP ProBook 4430s:
14.0-inch diagonal LED-backlit HD anti-glare (1366 x 768 resolution)
14.0-inch diagonal LED-backlit HD BrightView (1366 x 768 resolution)
HP ProBook 4530s:
15.6-inch diagonal LED-backlit HD anti-glare (1366 x 768 resolution)
15.6-inch diagonal LED-backlit HD BrightView (1366 x 768 resolution)
15.6-inch diagonal LED-backlit HD+ WVA anti-glare (1600 x 900 resolution)
HP ProBook 4730s:
17.3-inch diagonal LED-backlit HD+ anti-glare (1600x900 resolution)
Optional HP Privacy Filter
External Up to 32-bit per pixel color depth
VGA port supports resolutions up to 2048 x 1536 at 75 Hz, and lower
resolutions at up to 100 Hz.
HDMI port supports direct connection to high-definition displays with up to
1920 x 1080 resolution and 7-channel audio with one convenient cable (not
included).
NOTE: Resolutions are dependent upon monitor capability, and resolution and
color depth settings.
QuickSpecs
HP ProBook 4330s Notebook PC
HP ProBook 4430s Notebook PC
HP ProBook 4530s Notebook PC
HP ProBook 4730s Notebook PC
Standard Features (availability may vary by country)
DA - 13948 Worldwide — Version 28 — August 2, 2012 Page 8

HP ProBook 4330s Specifications

General

HDD speed	7200 RPM
HDD interface	SATA II
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	320 GB
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Bus type	DMI
Stepping	J1
Tjunction	100 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-2410M
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-2400 Mobile Series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Sandy Bridge
Processor frequency	2.3 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.9 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x8, 1x16, 2x4, 2x8
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	23
Maximum number of PCI Express lanes	16
Display surface	Matt
Display diagonal	13.3 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Power supply type	AC/DC
Intel segment tagging	Enterprise
Audio system	Premium Sound
Bluetooth version	3.0+HS
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Linux
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Battery life (max)	6 h
Number of battery cells	6
AC adapter power	65 W
Operating temperature (T-T)	5 - 35 °C
Sustainability certificates	ENERGY STAR
Product color	Black
Housing material	Aluminum
Country of origin	China
Pointing device	Touchpad
On-board graphics card ID	0x116
Discrete graphics card model	Intel® HD Graphics 3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1200 MHz
Processor ARK ID	52224
Processor package size	37.5x37.5 (rPGA988B); 31 x 24 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	235 mm
Width	330 mm
Height	27.9 mm
Weight	2000 g
