HP ProBook 4330s Quickspecs

Memory Standard DDR3 PC3-10600 SDRAM (1333 MHz)
Two SODIMM slots supporting dual-channel memory
1 GB, 2 GB, and 4 GB SODIMMs
Maximum Upgradeable to 8 GB with 4 GB SODIMMs
in slots 1 and 2
Dual-channel Maximized dual-channel performance requires SODIMMs of the same size and
speed in both memory slots.
NOTE: Due to the non-industry standard nature of some third-party memory modules, we recommend HP
branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the lower
memory speed. Full availability of 4 GB or more of memory requires Windows Vista Business 64-bit or
Linux. With Windows 32-bit operating systems, the amount of usable memory is dependent upon your
configuration, so that above 3 GB all memory may not be available due to system resource requirements.
Communications Realtek Ethernet (10/100/1000 NIC) *
Optional 56K V.92 modem **
* The term "10/100/1000" or "Gigabit" Ethernet indicates compatibility with IEEE standard 802.3ab for
Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed transmission,
connection to a Gigabit Ethernet server and network infrastructure is required.
** Designed for downloads from 56K modem compliant sources. Maximum achievable download
transmission rates currently do not reach 56 KB/s, and will vary with line conditions. Modem availability is
subject to country regulatory approval.
Wireless Devices Support for a broad range of secure, integrated wireless options featuring support for the latest industry
standards.
Mobile Broadband
options
Mobile Broadband (WWAN) requires a Windows operating system and is
available in select countries as a factory configurable feature for the HP
ProBook 4330s and 4530s with integrated graphics only. Two
850/900/1575/1700/1800/1900/2100 MHz antennas integrated in the top of
the display panel support current and future WWAN technologies.
NOTE: Separately purchased mobile network operator service is required.
HP lc2010 HSPA Mobile
Broadband Module
Integrated mobile broadband module that provides connectivity to UMTS
(HSPA) networks.
HP un2430 EV-DO/HSPA
Mobile Broadband Module
(availability expected May,
2011)
Integrated mobile broadband module with Gobi global mobile Internet
technology that provides connectivity to both CDMA (EVDO) and UMTS (HSPA)
networks. It also provides GPS functionality for various mapping applications
and security applications such as Computrace Pro for HP ProtectTools.
HP hs2340 HSPA+ Mobile
Broadband Module
Integrated mobile broadband module that provides connectivity to both HSPA
and HSPA+ (UMTS) networks. It also provides standalone, Internet and
network assisted GPS functionality for various mapping applications and
security applications such as Computrace Pro for HP ProtectTools.
802.11 integrated
wireless LAN options
Wi-Fi certified*
Wired Equivalent Privacy (WEP) support up to 128-bit keys
QuickSpecs
HP ProBook 4330s Notebook PC
HP ProBook 4430s Notebook PC
HP ProBook 4530s Notebook PC
HP ProBook 4730s Notebook PC
Standard Features (availability may vary by country)
DA - 13948 Worldwide — Version 28 — August 2, 2012 Page 9

HP ProBook 4330s Specifications

General

HDD speed	7200 RPM
HDD interface	SATA II
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	320 GB
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Bus type	DMI
Stepping	J1
Tjunction	100 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-2410M
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-2400 Mobile Series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Sandy Bridge
Processor frequency	2.3 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.9 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x8, 1x16, 2x4, 2x8
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	23
Maximum number of PCI Express lanes	16
Display surface	Matt
Display diagonal	13.3 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Power supply type	AC/DC
Intel segment tagging	Enterprise
Audio system	Premium Sound
Bluetooth version	3.0+HS
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Linux
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Battery life (max)	6 h
Number of battery cells	6
AC adapter power	65 W
Operating temperature (T-T)	5 - 35 °C
Sustainability certificates	ENERGY STAR
Product color	Black
Housing material	Aluminum
Country of origin	China
Pointing device	Touchpad
On-board graphics card ID	0x116
Discrete graphics card model	Intel® HD Graphics 3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1200 MHz
Processor ARK ID	52224
Processor package size	37.5x37.5 (rPGA988B); 31 x 24 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	235 mm
Width	330 mm
Height	27.9 mm
Weight	2000 g
