HP ProBook 440 G1 - Page 90

3. Lift the processor (2) straight up and remove it.
NOTE: The gold triangle (3) on the processor must be aligned with the triangle embossed on
the processor slot (4) when you install the processor.
Reverse this procedure to install the processor.
78 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
