Item Description Spare part number
(1) Display panel assembly, 35.6-cm (14.0-inch)
NOTE: Touch displays are not spared an the subcomponent level – touch display are only spared
as full hinge-ups.
Non-touch displays are ONLY spared at the subcomponent level – non-touch displays are not
spared as full-hinge-ups. For more information about non-touch display components, see Display
components on page 22.
Touch screen (full hinge-up), includes one antenna 826400-001
Touch screen (full hinge-up), includes two antennas 826401-001
(2) Keyboard (includes cable)
NOTE: For a detailed list of keyboard country codes, see Keyboard on page 42.
No backlight 826367-xxx
Backlit 826368-xxx
(3) Top cover (includes touchpad assembly) 829015-001
(4) USB/audio/card reader board 826374-001
(5) Power button board assembly 826387-001
(6) Function board 826381-001
(7) Fingerprint reader assembly (includes cable and bracket) 829011-001
(8) System board (includes replacement thermal material)
All system boards use the following part numbers:
xxxxxx-001: Windows 7 or non-Windows operating systems
xxxxxx-601: Windows 8.1 or Windows 10 operating system
Intel Core i7-6500U processor; 2-GB discrete graphics memory 830947-xxx
Intel Core i5-6300U processor; 2-GB discrete graphics memory 830946-xxx
Intel Core i5-6200U processor; 2-GB discrete graphics memory 830945-xxx
Intel Core i3-6100U processor; 2-GB discrete graphics memory 830944-xxx
Intel Core i3-6100U processor; 1-GB discrete graphics memory 830943-xxx
Intel Core i7-6500U processor; UMA graphics memory 830940-xxx
Intel Core i5-6300U processor; UMA graphics memory 830939-xxx
Intel Core i5-6200U processor; UMA graphics memory 830937-xxx
Intel Core i3-6100U processor; UMA graphics memory 830935-xxx
Intel Pentium 4405U processor; UMA graphics memory 830942-xxx
Intel Celeron 3855U processor; UMA graphics memory 830934-xxx
Heat sink assembly (includes replacement thermal material)
(9) For use in models with discrete graphics 826404-001
(10) For use in models with UMA graphics 829012-001
(11) Fan 829010-001
20 Chapter 3 Illustrated parts catalog
