Item Description Spare part number
(12) RTC battery 826388-001
(13) Speaker assembly 829014-001
(14) Power connector cable 827039-001
(15) Battery, Li-ion
6-cell, 55 WHr, 2.8 Ah 811347-001
4-cell, 44 WHr, 3.0 Ah 805292-001
(16) Base enclosure 829008-001
(17) Hard drive
1 TB, 5400 rpm, 7 mm 762990-001
750 GB, 5400 rpm, 7 mm 752099-001
500 GB, 5400 rpm, 7 mm 778186-001
500 GB, 5400 rpm, 7 mm, hybrid (8-GB SSD) 732000-001
500 GB, 7200 rpm, 7 mm 703267-001
(18) Hard drive Hardware Kit (includes bracket and screws) 826382-001
(19) Memory modules (PC3L-12800, 1600-MHz, DDR3L)
8-GB 693374-001
4-GB 691740-001
2-GB 691739-001
(20) WLAN module
Realtek RTL8188EE 802.11b/g/n 1x1 Wi-Fi Adapter (Worldwide) 792609-001
Realtek RTL8723BE 802.11b/g/n 1x1 Wi-Fi + BT4.0 Combo Adapter (Worldwide) 792610-001
Realtek RTL8723BE bgn 1x1 + BT 4 LE PCIe+USB NGFF 2230 M.2 (Worldwide) 792611-001
Broadcom 943228 abgn 2x2 + BT 4 LE PCIe+USB NGFF 2230 MOW (Most of World) 797884-001
7260NGW Intel Dual Band Wireless-AC 7260 802.11ac, Dual Band, 2x2 Wi-Fi + Bluetooth 4.0 806722-001
Intel Dual Band Wireless-AC 3165 802.11ac, Dual Band, 1×1 Wi-Fi + Bluetooth 4.0 (Most of World) 806723-001
Intel Dual Band Wireless-AC 3160 802.11ac, Dual Band, 1x1, Wi-Fi + Bluetooth 4.0 (only for use in
Brazil)
810813-205
(21) Solid-state drive, M.2
256-GB, TLC 826393-001
128-GB, TLC 826392-001
Plastics Kit, includes: 829013-001
(22) Service door
Fingerprint reader insert (for models without a ngerprint reader)(not illustrated)
Computer major components 21
