Page #7 background imageLoading...
Page #7 background image
GRAPHICS
Integrated:
Intel HD Graphics 4000 (3nd Generation Intel Quad-Core i7; Dual-Core i5 and i3)
Intel HD Graphics 3000 (2nd Generation Intel Dual-Core i5 and i3)
Intel HD Graphics (2nd Generation Intel configurations)
Discrete (4540s):
AMD Radeon™ HD 7650M, with 1 GB and 2 GB dedicated DDR3 video memory
DISPLAY
HP ProBook 4440s:
Internal
14" diagonal LED-backlit HD anti-glare (1366 x 768)
External
Up to 32-bit per pixel color depth
VGA
Port supports resolutions up to 2048 x 1536 external resolution @75 Hz
HDMI
Supports direct connection to high-definition displays with up to 1920 x 1200@60Hz resolution and 7-channel audio with one
convenient cable (not included)
HP ProBook 4540s:
Internal
15.6" diagonal LED-backlit HD anti-glare (1366 x 768)
External
Up to 32-bit per pixel color depth
VGA
Port supports resolutions up to 2048 x 1536 external resolution @75 Hz
HDMI
Supports direct connection to high-definition displays with up to 1920 x 1200@60Hz resolution and 7-channel audio with one
convenient cable (not included)
NOTE:
HD content required to view HD images.
NOTE:
Resolutions are dependent upon monitor capability, and resolution and color depth settings.
QuickSpecs
HP ProBook 4440s/1s Notebook PC
HP ProBook 4540s Notebook PC
Features
DA - 14306 North America — Version 7 — April 25, 2013
Page 7

Other manuals for HP ProBook 4440s

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP ProBook 4440s and is the answer not in the manual?

HP ProBook 4440s Specifications

General IconGeneral
Bus typeDMI
Tjunction105 °C
Processor cache3 MB
Processor cores2
System bus rate5 GT/s
Processor familyIntel® Core™ i3
Processor seriesIntel Core i3-3100 Mobile Series
Processor socket-
Processor threads4
Processor codenameIvy Bridge
Processor frequency2.5 GHz
Processor cache typeSmart Cache
Processor lithography22 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)35 W
CPU multiplier (bus/core ratio)25
Maximum number of PCI Express lanes16
Motherboard chipsetIntel HM76 Express
Memory slots2x SO-DIMM
Internal memory4 GB
Memory clock speed1333 MHz
Internal memory typeDDR3-SDRAM
Maximum internal memory- GB
HDD size2.5 \
HDD speed7200 RPM
HDD interfaceSATA
Storage mediaHDD
Optical drive typeDVD Super Multi DL
Card reader integratedYes
Total storage capacity500 GB
Number of HDDs installed1
Panel typeTN
Pixel pitch0.227 x 0.227 mm
Display diagonal14 \
Display brightness200 cd/m²
Display resolution1366 x 768 pixels
Native aspect ratio16:9
Contrast ratio (typical)400:1
On-board graphics card ID0x166
Discrete graphics card modelNot available
On-board graphics card modelIntel® HD Graphics 4000
On-board graphics card familyIntel® HD Graphics
On-board graphics card base frequency650 MHz
On-board graphics card dynamic frequency (max)1100 MHz
Disc types supportedCD-R, CD-RW, DVD+R, DVD+R DL, DVD+RW, DVD-R, DVD-R DL, DVD-RW
Intel segment taggingEnterprise
Audio systemSRS Premium PRO
Front camera resolution1280 x 720 pixels
Data networkNot supported
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version4.0
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates10, 100, 1000 Mbit/s
Charging port typeDC-in jack
Headphone connectivity3.5 mm
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 2.0 ports quantity0
Pointing deviceTouchpad
Bundled softwareCyberlink Media Suite\\r HP Recovery Manager\\r HP Support Assistant\\r Software HP Hotkey Support\\r HP Peak Power Manager\\r HP Power Assistant\\r HP Connection Manager\\r HP Wireless Hotspot\\r HP Wireless Assistant\\r ArcSoft Total Media Suite\\r WinZip
Operating system installedWindows 7 Professional
Form factorClamshell
Product typeLaptop
Product colorSilver
Housing materialAluminium, Plastic
Country of originChina
Processor ARK ID71465
Processor package size37.5 x 37.5 (rPGA988B); 31 x 24 (BGA1023) mm
Supported instruction setsAVX
Intel Identity Protection Technology version1.00
Battery capacity47 Wh
Battery life (max)7.5 h
Number of battery cells6
AC adapter power65 W
Cables includedAC
Sustainability certificatesENERGY STAR
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 35 °C
Storage relative humidity (H-H)5 - 95 %
Operating relative humidity (H-H)10 - 90 %
Weight and Dimensions IconWeight and Dimensions
Depth235 mm
Width339 mm
Height28 mm
Weight2070 g
