Table 3-2 Display components and their descriptions
Item Description Spare part number
(1) Display bezel (includes camera)
For use in models with an HD camera L77285-001
For use in models with and HD + IR camera L77286-001
For use in models without a camera L77287-001
Camera module (includes bezel adhesive and display enclosure adhesive)
(2) HD L83709-001
(3) HD + IR L83710-001
Microphone board (not illustrated) L44541-001
(4) Display panel (raw) (includes bezel adhesive and display enclosure adhesive)
HD L79185-001
FHD, touch-on panel (TOP) L79186-001
FHD, privacy L79187-001
FHD, not privacy L79188-001
Display/camera cable assembly (includes bezel adhesive and display enclosure adhesive)
(5) For use in models with an HD camera L77270-001
For use in models with an HD camera and privacy panel L77269-001
(6) For use in models with an HD + IR camera and privacy panel L77271-001
For use in models with an HD + IR camera and without a privacy panel L77272-001
For use in models with a touch panel L77273-001
(7) WWAN antennas (includes bezel adhesive and display enclosure adhesive) L77284-001
(8) WLAN antennas (includes bezel adhesive and display enclosure adhesive) L77283-001
(9) Hinge Kit (left and right) (includes bezel adhesive and display enclosure adhesive) L79189-001
(10) Display rear cover (includes wireless antennas and bezel adhesive)
For use in models with an HD camera, without WWAN L77277-001
For use in models with an HD camera and privacy panel, without WWAN L77278-001
For use in models with an HD + IR camera and nontouch panel, without WWAN L77279-001
For use in models with an HD + IR camera and privacy panel, without WWAN L77280-001
For use in models with an HD camera, nontouch panel, and WWAN L77281-001
For use in models with an HD camera, touch panel, and WWAN L77282-001
Camera privacy cover (not illustrated) L77237-001
Display components 21
