NOTE: For UMA models, thoroughly clean thermal material from the surface of the system board
(1) and from the heat sink (2) each time you remove the heat sink. All heat sink and processor spare
part kits include thermal material.
Reverse this procedure to install the heat sink.
Processor
NOTE: All processor spare part kits include replacement thermal material.
Description Spare part number
AMD A4-4300M APU (3.0-GHz/2.5-GHz, 1-MB L2 cache) 685990-001
AMD A6-4400M APU (3.2-GHz/2.7-GHz, 1-MB L2 cache) 683047-001
AMD A8-4500M APU (2.8-GHz/1.9-GHz, 4-MB L2 cache) 683048-001
56 Chapter 4 Removal and replacement procedures
