RTC battery
Description Spare part number
RTC battery not spared
Before removing the RTC battery, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet, and
then unplugging the AC adapter from the computer.
4. Remove the following components:
a. Service door (see Service door on page 33).
b. Hard drive (see Hard drive on page 36)
c. Optical drive (Optical drive on page 34)
d. WLAN module (see WLAN/Bluetooth combo card on page 40)
e. WWAN module (see WWAN module on page 42)
f. Keyboard (see Keyboard on page 45)
g. Top cover (see Top cover on page 52)
h. Battery (see Battery on page 66)
i. System board (see System board on page 74)
Remove the RTC battery:
1. Position the system board upside-down.
2. Use a tool to pry the battery out of the socket (1).
Component replacement procedures 77
