HP ProBook 5330m User Manual

Category Description
Supports the following hard drives:
●
500 GB, 7200-rpm
●
320 GB Self-Encrypting Drive (SED), 7200-rpm
●
320 GB, 7200-rpm
● 250 GB, 7200-rpm
Supports the following solid-state drive:
●
128 GB
HP 3D DriveGuard (not available with Linux)
Audio/Visual Beats audio
Integrated microphone (dual-array)
Two stereo speakers
Integrated 720p webcam
Ethernet 10/100/1000 Ethernet network interface card (NIC)
S3/S4/S5 wake on LAN (AC only mode)
Wireless Integrated WLAN options by way of wireless module
Support for the following WLAN formats:
●
Broadcom 43224 802.11a/b/g/n WiFi Adapter
●
Broadcom 4313 802.11b/g/n 1x1 WiFi Adapter
●
Intel Centrino® Advanced N 6205 802.11a/b/g/n, 2x2 WiFi Adapter
2 WLAN antennas built into display assembly
Support for no-WLAN option
Integrated personal area network (PAN) options by way of Bluetooth®
module:
Support for no-WPAN option
HP Integrated Module with Bluetooth 2.1 Wireless Technology
Integrated WWAN options by way of WWAN module (not available with Linux)
HP un2430 EV-DO/HSPA Mobile Broadband Module (select models only)
HP hs2340 HSPA+ Mobile Broadband Module
Support for no-WWAN option
Subscriber identity module (SIM) security (customer-accessible in battery bay)
External media cards Integrated SD flash media slot supporting Secure Digital (SD) and MultiMediaCard
(MMC)
Ports Audio in/Audio-out (stereo microphone/headphone)
RJ-45 (Ethernet, includes link and activity lights)
USB 2.0 (2), one with USB charging
Combo eSATA/USB 2.0 (1)
2 Chapter 1 Product description

HP ProBook 5330m Specifications

General

Bus type	DMI
Stepping	J1
Tjunction	100 °C
Processor cache	3 MB
Processor cores	2
System bus rate	5 GT/s
Processor family	Intel® Core™ i3
Processor series	Intel Core i3-2300 Mobile Series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Sandy Bridge
Processor frequency	2.1 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	21
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM67 Express
HDD speed	7200 RPM
HDD interface	SATA II
Optical drive type	-
Card reader integrated	Yes
Total storage capacity	500 GB
Compatible memory cards	MMC, SD
Number of HDDs installed	1
Display diagonal	13.3 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Power supply type	AC/DC
Intel segment tagging	Enterprise
Operating temperature (T-T)	41 - 95 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Memory slots	1x SO-DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Memory slots (available)	0
Pointing device	Touchpad
Bluetooth version	2.1+EDR
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Windows 7 Professional
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Cable lock slot type	Kensington
Battery capacity	41 Wh
Battery life (max)	5.5 h
AC adapter power	65 W
Sustainability certificates	EPEAT Gold, ENERGY STAR
Product color	Black, Silver
Country of origin	China
On-board graphics card ID	0x116
Discrete graphics card model	Intel® HD Graphics 3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1100 MHz
Processor code	SR04S
Processor ARK ID	52220
Processor package size	37.5 x 37.5 xrPGA988B); 31 x 24 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	225 mm
Width	328 mm
Height	25.2 mm
Weight	1820 g
