33.8 cm (13.3 in) display specifications
Dimensions
Height 16.3 cm (6.4 in)
Width 26.1 cm (10.3 in)
Diagonal 33.8 cm (13.3 in)
Number of colors Up to 16.8 million
Contrast ratio 300:1 (typical)
Brightness 200 nits (typical)
Pixel resolution
Pitch 0.204 × 0.204 mm
Format SD: 1280×800
Configuration RGB vertical stripe
Backlight LED
Character display 80 × 25
Total power consumption 4.0 W
Viewing angle ±30° horizontal, ±10° vertical (minimum)
102 Chapter 6 Specifications
