HP ProBook 6450b Specification

QuickSpecs
HP ProBook 6450b Notebook PC
HP ProBook 6550b Notebook PC
Standard Features (availability may vary by country)
DA
–
13616
E
MEA
—
Version
1
—
M
ay
, 2010
Page
10
802.11a/b/g/n
WiFi Adapter
Up to 300 mbps data rate
Broadcom 4313GN
802.11b/g/n
WiFi Adapter
Integrated support for 802.11 b, g, and n
Up to 72 mbps data rate
HP Integrated
Module with
Bluetooth 2.1+EDR
Wireless Technology
Bluetooth Specification v2.1+EDR compliant
Works with a wide range of Bluetooth devices
Keyboard
The HP spill
-
resistant keyboard is designed using a thin layer o
f Mylar film under the keyboard
and a drain system that funnels fluid through a hole in the bottom of the notebook. This minimizes
the risk of damage to sensitive components underneath. The 101/102-key compatible keyboard
features a full-pitch key layout with desktop keyboard features, such as the isolated inverted-T
cursor control keys, editing keys, both left and right control and alt keys, 12 function keys, and
19.05 x 19.05 mm key pitch (center-to-center spacing). U.S. and International key layouts are
available. Other features include hotkeys for instant access to power conservation and
brightness. The HP ProBook 6550b includes a separate numeric keypad.
Touch-sensitive
controls
Touch
-
sensitive controls provide easy access to the following features
: HP QuickLook 3, HP
QuickWeb, wireless on/off, volume mute, volume down, volume up. The HP ProBook 6550b
also features a calculator button.
Pointing device
Touchpad with scroll zone, two pick buttons
Optional pointstick with two additional pointstick buttons
Expansion card slots
ExpressCard/54 slot
Supports ExpressCard/54 and ExpressCard/34
or
Optional Integrated
Smart Card Reader
(replaces
ExpressCard/54 slot)
Compatible with ISO 7816 compliant Smart Cards
PC/SC interface support
Media
Card Reader
Supports SD (Secure Digital), HC
-
SD (High Capacity Secure Digital),
MMC (MultiMedia Card), HS-MMC (MultiMedia Card Plus), Sony
Memory Stick, Sony Memory Stick Pro, Memory Stick Duo*, xD-Picture
card
Additionally, the following cards are supported via passive adapters
(sold separately): Mini-Secure Digital (Mini-SD), Transflash (Micro-SD),
Reduced size Multimedia card (RS-MMC), Reduced size Dual voltage
Multimedia card, MMC Mobile Cards, MMC Micro Cards, Memory
Stick Duo (MS Duo)*, Memory Stick Duo Pro (MS Duo Pro)*, Memory
Stick M2 Micro

HP ProBook 6450b Specifications

General

Bus type	DMI
Stepping	C2
Tjunction	105 °C
Processor cache	2 MB
Processor cores	2
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-500 Mobile Series
Processor socket	BGA 956
Processor threads	4
Processor codename	Arrandale
Processing Die size	81 mm²
Processor frequency	2.4 GHz
Processor cache type	L2
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.93 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	18
Maximum number of PCI Express lanes	16
Number of Processing Die Transistors	382 M
Motherboard chipset	Intel® HM57 Express
HDD speed	7200 RPM
HDD interface	SATA II
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	250 GB
Number of HDDs installed	1
Display diagonal	14 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Power supply type	AC/DC
Intel segment tagging	Enterprise
Operating temperature (T-T)	41 - 95 °F
Compliance industry standards	IEEE802.3, IEEE802.3u, IEEE802.3ab
Memory slots	2x SO-DIMM
Internal memory	2 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Pointing device	Touchpad
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Windows 7 Professional
Operating system architecture	32-bit
ExpressCard slot	-
Charging port type	DC-in jack
USB 2.0 ports quantity	3
CardBus PCMCIA slots quantity	0
AC adapter power	65 W
Battery capacity	55 Wh
Number of battery cells	6
Storage relative humidity (H-H)	5 - 95 %
Product color	Black, Silver
Country of origin	China
Discrete graphics card model	Intel® HD Graphics
On-board graphics card base frequency	500 MHz
On-board graphics card dynamic frequency (max)	766 MHz
Processor ARK ID	47341
Processor package size	rPGA 37.5x 37.5, BGA 34x28 mm
Graphics & IMC lithography	45 nm
Supported instruction sets	SSE4.1/4.2
Intel® Turbo Boost Technology	1.0
Physical Address Extension (PAE)	36 bit

Weight and Dimensions

Depth	236.2 mm
Width	339 mm
Height	33.8 mm
Weight	2260 g
