HP ProBook 6450b Specification

QuickSpecs
HP ProBook 6450b Notebook PC
HP ProBook 6550b Notebook PC
Standard Features (availability may vary by country)
DA
–
13616
E
MEA
—
Version
1
—
M
ay
, 2010
Page
14
provisioning, credential reset, and system and
network revocation . Central Management is
available in two feature levels:
 Digital Persona Pro Enterprise: Designed for environments with Active Directory. For
large businesses, as well as smaller businesses utilizing an active directory based
infrastructure. Gives IT Managers the ability to create role based security policies,
provision users, and create login policies based on passwords, biometrics or smart
cards. Management features also include remote credential recovery in case the user
forgets the password, loses the smart card, or cannot use the fingerprint reader for any
reason. In addition, advanced auditing capabilities are also built in.
 Digital Persona Workgroup Manager: Designed for environments without Active
Directory. This option can be used by smaller businesses as well as workgroups within
large organizations. Workgroup Manager offers features similar to Digital Persona Pro
Enterprise, but without active directory integration. Workgroup activation is built into HP
ProtectTools, and activation of up to 5 seats is completely free.
Power Supply
Models with discrete graphics:
External 90-watt Smart AC adapter
Models with integrated graphics:
External 65-watt Smart AC adapter
Power cord included is 1.8 meter (6-foot).
Total length including external AC adapter is 3.66 meter (12 feet).
HP Fast Charge*
*HP Fast Charge recharges your battery up to 90% within 90 minutes when the system is off. HP
Fast Charge does not apply to the 9-cell primary battery or the 12-cell Ultra-Capacity batteries.
Battery Primary battery
HP 9-cell (93 WHr) Li-Ion battery
HP 6-cell (55 WHr) Li-Ion battery
HP Long Life 6-cell (51 WHr) Battery (with 3-year platform warranty
only)
Optional HP Long
Life Battery
3
-
cell (47 WHr) Li
-
Ion battery
Optional HP
Extended Life
Battery
8
-
cell (52 WHr) Li
-
Ion battery
Optional HP Ultra-
Capacity Battery
12
-
cell (95 WHr) Li
-
Ion battery
Battery Life HP 9-cell (93 WHr)
Primary
HP 6-cell (55 WHr)
Primary
HP Long Life 6-cell
(51 WHr)
Primary battery
Up to
1
1
hours
Up to
6
h 30min
Up to
6
hours

HP ProBook 6450b Specifications

General

Bus type	DMI
Stepping	C2
Tjunction	105 °C
Processor cache	2 MB
Processor cores	2
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-500 Mobile Series
Processor socket	BGA 956
Processor threads	4
Processor codename	Arrandale
Processing Die size	81 mm²
Processor frequency	2.4 GHz
Processor cache type	L2
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.93 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	18
Maximum number of PCI Express lanes	16
Number of Processing Die Transistors	382 M
Motherboard chipset	Intel® HM57 Express
HDD speed	7200 RPM
HDD interface	SATA II
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	250 GB
Number of HDDs installed	1
Display diagonal	14 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Power supply type	AC/DC
Intel segment tagging	Enterprise
Operating temperature (T-T)	41 - 95 °F
Compliance industry standards	IEEE802.3, IEEE802.3u, IEEE802.3ab
Memory slots	2x SO-DIMM
Internal memory	2 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Pointing device	Touchpad
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Windows 7 Professional
Operating system architecture	32-bit
ExpressCard slot	-
Charging port type	DC-in jack
USB 2.0 ports quantity	3
CardBus PCMCIA slots quantity	0
AC adapter power	65 W
Battery capacity	55 Wh
Number of battery cells	6
Storage relative humidity (H-H)	5 - 95 %
Product color	Black, Silver
Country of origin	China
Discrete graphics card model	Intel® HD Graphics
On-board graphics card base frequency	500 MHz
On-board graphics card dynamic frequency (max)	766 MHz
Processor ARK ID	47341
Processor package size	rPGA 37.5x 37.5, BGA 34x28 mm
Graphics & IMC lithography	45 nm
Supported instruction sets	SSE4.1/4.2
Intel® Turbo Boost Technology	1.0
Physical Address Extension (PAE)	36 bit

Weight and Dimensions

Depth	236.2 mm
Width	339 mm
Height	33.8 mm
Weight	2260 g
