HP ProBook 6450b Specification

QuickSpecs
HP ProBook 6450b Notebook PC
HP ProBook 6550b Notebook PC
Standard Features (availability may vary by country)
DA
–
13616
E
MEA
—
Version
1
—
M
ay
, 2010
Page
8
Chipset
Mobile Intel HM57 Express Chipset (non vPro configurations)
Graphics
Mode
ls with discrete graphics
(6550b only)
:
ATI Mobility Radeon™ HD 540v with 512 MB dedicated video memory
Microsoft DirectX 10.1 (Shader Model 4.1) and OpenGL 2.1 capable
Models with integrated graphics (6450b and 6550b):
Intel HD Graphics
Microsoft DirectX 10 (Shader Model 4.0) and OpenGL 2.0 capable
Display Internal
HP ProBook 6450b:
35.6cm (14.0-inch) diagonal LED-backlit HD anti-glare (1366 x 768
resolution)
35.6cm (14.0-inch) diagonal LED-backlit HD+ anti-glare (1600 x 900
resolution)
HP ProBook 6550b:
39.6cm (15.6-inch) diagonal LED-backlit HD anti-glare (1366 x 768
resolution)
39.6cm (15.6-inch) diagonal LED-backlit HD+ WVA anti-
glare (1600 x
900 resolution)
HP Privacy Filter support
External
Up to 32
-
bit per pixel color depth
DisplayPort supports resolutions up to 2560 x 1600, 30-bit color
depth at 60 Hz, and full HD (1920 x 1080) monitors, 24-bit color
depth at 120 Hz
VGA port supports resolutions up to 2048 x 1536 at 75 Hz, and
lower resolutions at up to 100 Hz
DVI-D (single link) video signal available through DVI port in optional
HP Docking Station (sold separately)
supports resolutions up to 1600 x 1200 at both full and reduced
blanking, and 1920 x 1200 at reduced blanking
NOTE: Resolutions are dependent upon monitor capability, and
resolution and color depth settings.
Memory
Standard
DDR3 PC3
-
10600 SDRAM (1333 MHz)
*
Two SODIMM slots supporting dual-channel memory
2048 MB and 4096 MB SODIMMs
Maximum
Upgradeable to 8192 MB with 4096 MB SODIMMs in slots 1 and 2
Dual-channel
Maximized dual-channel performance requires SODIMMs of the same
size and speed in both memory slots.
* M
emory speed is processor dependent.

HP ProBook 6450b Specifications

General

Bus type	DMI
Stepping	C2
Tjunction	105 °C
Processor cache	2 MB
Processor cores	2
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-500 Mobile Series
Processor socket	BGA 956
Processor threads	4
Processor codename	Arrandale
Processing Die size	81 mm²
Processor frequency	2.4 GHz
Processor cache type	L2
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.93 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	18
Maximum number of PCI Express lanes	16
Number of Processing Die Transistors	382 M
Motherboard chipset	Intel® HM57 Express
HDD speed	7200 RPM
HDD interface	SATA II
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	250 GB
Number of HDDs installed	1
Display diagonal	14 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Power supply type	AC/DC
Intel segment tagging	Enterprise
Operating temperature (T-T)	41 - 95 °F
Compliance industry standards	IEEE802.3, IEEE802.3u, IEEE802.3ab
Memory slots	2x SO-DIMM
Internal memory	2 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Pointing device	Touchpad
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Windows 7 Professional
Operating system architecture	32-bit
ExpressCard slot	-
Charging port type	DC-in jack
USB 2.0 ports quantity	3
CardBus PCMCIA slots quantity	0
AC adapter power	65 W
Battery capacity	55 Wh
Number of battery cells	6
Storage relative humidity (H-H)	5 - 95 %
Product color	Black, Silver
Country of origin	China
Discrete graphics card model	Intel® HD Graphics
On-board graphics card base frequency	500 MHz
On-board graphics card dynamic frequency (max)	766 MHz
Processor ARK ID	47341
Processor package size	rPGA 37.5x 37.5, BGA 34x28 mm
Graphics & IMC lithography	45 nm
Supported instruction sets	SSE4.1/4.2
Intel® Turbo Boost Technology	1.0
Physical Address Extension (PAE)	36 bit

Weight and Dimensions

Depth	236.2 mm
Width	339 mm
Height	33.8 mm
Weight	2260 g
