RJ-11 connector cable
NOTE: The RJ-11 connector cable is included in the Cable Kit, spare part number 641830-001.
Before removing the RJ-11 connector cable, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet,
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 41).
5. Remove the following components:
a. Remove the bottom door (see
Bottom door on page 48).
b. Hard drive (see
Hard drive on page 53)
c. Optical drive (see
Optical drive on page 49)
d. WLAN module (see
WLAN module on page 59)
e. WWAN module (see
WWAN module on page 57)
f. Modem module (see
Modem module on page 62)
g. Fan (see
Fan on page 63)
h. Heat sink (see
Heat sink on page 64)
i. Keyboard (see
Keyboard on page 67)
j. Bottom cover (see
Bottom cover from top cover on page 70)
Remove the RJ-11 connector cable:
1. Position the bottom cover with the front toward you.
2. Remove the RJ-11 connector (1) from the clip built into the base enclosure.
Component replacement procedures 81
