8 Connector pin assignments
1394
Pin Signal
1Power
2Ground
3TPB-
4TPB+
5TPA-
6TPA+
Audio-in (microphone)
Pin Signal
1 Audio signal in
2 Audio signal in
3Ground
1394
193
