SuSE Linux (SLED)
Recovery after a system failure is as good as your most recent backup. As you add new software and
data files, you should continue to back up your system on a regular basis to maintain a reasonably
current backup.
Your computer includes tools provided by HP to help you safeguard your information and retrieve it if
ever needed.
Creating backups
1. Create restore media immediately after you set up the computer. For more information, see the
“Performing a system recovery” section.
2. As you add files, routinely create a backup of your system and personal information.
Backing up your information
You should back up your computer files on a regular schedule to maintain a current backup. You can
manually back up your information to an optional external drive, a network drive, or discs. Back up
your system at the following times:
At regularly scheduled times
Before the computer is repaired or restored
Before you add or modify hardware or software
To back up your home directory files using Backup Manager Settings:
1. Select Computer > More Applications > Tools > Backup Manager Settings, and click
Backup my home directory.
2. Click Storage Destination Location, and then select a location to back up your information.
3. Click Schedule, and then select a time schedule to perform backups at a regularly scheduled
time.
To immediately back up your information, click the Backup Now check box.
NOTE: Before you back up your information, be sure you have designated a location to save
the backup files.
4. Click Save and Backup to start the backup and to save the backup settings.
To restore backup files:
1. Select Computer > More Applications > Tools > Backup Manager Restore.
2. Click Backup Source, and then select the location of the backup files.
3. Click Restore Destination, and then select the destination to restore the files.
174 Chapter 7 Backup and recovery

Table of Contents

Other manuals for HP ProBook 6570b

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP ProBook 6570b and is the answer not in the manual?

HP ProBook 6570b Specifications

General IconGeneral
Bus typeDMI
SteppingL1
Tjunction90 °C
Processor cache3 MB
Processor cores2
Processor modeli3-3110M
System bus rate5 GT/s
Processor familyIntel® Core™ i3
Processor seriesIntel Core i3-3100 Mobile Series
Processor socketBGA 1023
Processor threads4
Processor codenameIvy Bridge
Processor frequency2.4 GHz
Processor cache typeSmart Cache
Processor lithography22 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)35 W
CPU multiplier (bus/core ratio)24
Maximum number of PCI Express lanes16
Motherboard chipsetIntel HM76 Express
Memory slots2x SO-DIMM
Internal memory4 GB
Memory clock speed1600 MHz
Internal memory typeDDR3-SDRAM
Maximum internal memory16 GB
HDD speed7200 RPM
HDD interfaceSATA II
Storage mediaHDD
Optical drive typeDVD Super Multi DL
Card reader integratedYes
Total storage capacity320 GB
Compatible memory cardsMMC, SD
Number of HDDs installed1
Display diagonal15.6 \
Display resolution1366 x 768 pixels
Native aspect ratio16:9
LightScribe-
Intel segment taggingEnterprise
Ethernet interface typeGigabit Ethernet
On-board graphics card ID0x166
Discrete graphics card modelNot available
On-board graphics card modelIntel® HD Graphics 4000
On-board graphics card familyIntel® HD Graphics
On-board graphics card base frequency650 MHz
On-board graphics card dynamic frequency (max)1000 MHz
Wi-Fi standards802.11a, 802.11b, 802.11g
Bluetooth version4.0
Cabling technology10/100/1000Base-T(X)
Ethernet LAN data rates10, 100, 1000 Mbit/s
Charging port typeDC-in jack
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 3.2 Gen 1 (3.1 Gen 1) ports quantity0
Pointing deviceTouchpad
Operating system installedWindows 7 Professional
Form factorClamshell
Product colorBlack
Country of originChina
Battery capacity55 Wh
Battery life (max)7.25 h
Number of battery cells6
AC adapter power65 W
Operating temperature (T-T)5 - 35 °C
Operating relative humidity (H-H)10 - 90 %
Sustainability certificatesENERGY STAR
Processor codeSR0N2
Processor ARK ID65700
Processor package size37.5 x 37.5 (rPGA988B); 31 x 24 (BGA1023) mm
Supported instruction setsAVX
Intel Identity Protection Technology version1.00
Weight and Dimensions IconWeight and Dimensions
Depth251 mm
Width374 mm
Height34 mm
Weight2510 g
