HP ProCurve 1410-24G

1-5
Introducing the Switch
Back of the Switch
Back of the Switch
Power Connector
The 1410-8G Switch and 1410-16G Switch do not have a power switch. They
are powered on when the external AC/DC power adapter is connected to the
switch and to a power source. The external AC/DC power adapter supplies
12 volts DC to the switch and automatically adjusts to any AC voltage between
100-240 volts and either 50 or 60 Hz. No voltage range settings are required.
The 1410-24G Switch does not have a power switch; it is powered on when
connected to an active AC power source. The switch automatically adjusts to
any AC voltage between 100-127 and 200-240 volts and either 50 or 60 Hz. There
are no voltage range settings required.
DC power connector
HP ProCurve 1410-8G Switch (J9559A)
HP ProCurve 1410-16G Switch (J9560A)
HP ProCurve 1410-24G Switch (J9561A)
Power cord retention ring
DC power connector Power cord retention ring
10/100/1000Base-T RJ-45 ports
AC power connector
Security cable slot
