HP ProCurve 1410-24G

2-10
Installing the Switch
Installation Procedures
Rack Mounting the Switch
Note Requires optional mounting bracket kit (not included).
1. Use a #1 Phillips (cross-head) screwdriver and attach the mounting
brackets to the switch with the included 8-mm M4 screws.
Figure 2-4. Attaching mounting brackets to the 1410-16G Switch
Figure 2-5. Attaching mounting brackets to the 1410-24G Switch
8 mm
M4 screws
8 mm
M4 screws
