4-4
Planning and Implementation for the 2600-PWR Switches
Planning the PoE Configuration
Planning and
Implementation for the 2600-
PWR Switches
A single 2626-PWR switch with a dedicated 600 RPS/EPS unit has fully
redundant PoE power for all 24 ports at 15.4 W per port.
Figure 4-3. Example of an 600 RPS/EPS Powering Two 2626-PWR Switches
Source of
Power
Watts
Available
# of Ports Powered and
Average watts/Port
Redundant # of Ports
Powered and Average watts/
Port
Internal PoE
Power
Supply
406 24 @ average 15.4 W each None
Internal plus
External PoE
Power
Supply
406 + 408
1 - 24
24 @ average 15.4 W each 24 @ average 15.4 W each
External PoE
Power
Supply
(Failed
Internal PoE
Power
Supply)
408 24 @ average 15.4 W each None
600 RPS/EPS
ProCurve Switch
2626-PWR
