Access Control Lists (ACLs) for the Series 3400cl and Series 6400cl Switches
Configuring and Assigning an ACL
A (Refer to figure 10-17, above.)
B (Refer to figure 10-17, above.)
write memory writes the configuration
changes to the startup-config file.
ACL 110, applied to port 1, consumes two per-
port rules and three ACL masks.
ACL 120, applied to port 2, also consumes
two per-port rules and three ACL masks.
Access-List configuration in the
switch’s startup-config file.
Figure 10-18. Example of Configuration Commands for an Extended ACL
10-53
