IP Routing Features
Configuring RIP
The resulting display will appear similar to the following:
HPswitch# show ip rip peer
RIP peer information
IP Address Bad routes Last update timeticks
--------------- ----------- ---------------------
100.1.0.100 0 1
100.2.0.100 0 0
100.3.0.100 0 2
100.10.0.100 0 1
Figure 11-5. Example of Show IP RIP Peer Output
This display lists all neighboring routers from which the routing switch has
received RIP updates. The following fields are displayed:
■IP Address – IP address of the RIP peer neighbor.
■Bad routes – The number of route entries that were not processed for
any reason.
■Last update timeticks – How many seconds have passed since the
routing switch received an update from this peer neighbor.
Displaying RIP information for a specific peer: For example, to show
the RIP peer information for the peer with IP address 100.1.0.100, enter show
ip rip peer 100.1.0.100.
HPswitch# show ip rip peer 100.0.1.100
RIP peer information for 100.0.1.100
IP Address : 100.1.0.100
Bad routes : 0
Last update timeticks : 2
Figure 11-6. Example of Show IP RIP Peer < ip-addr > Output
This display lists the following information for a specific RIP peer:
■IP Address – IP address of the RIP peer neighbor.
■Bad routes – The number of route entries which were not processed for
any reason.
■Last update timeticks – How many seconds have passed since the
routing switch received an update from this neighbor.
11-32
