5-69

Quality of Service: Managing Bandwidth More Effectively

Globally-Configured QoS

Figure 5-32. Global Source-Port Classifier with DSCP-Priority Marking

Radius Override Field. During a client session authenticated by a RADIUS

server, the server can impose a port priority that applies only to that client

session. Refer to the RADIUS chapter in the Access Security Guide for your

switch.

Switch(eth-A2)# int e b4,c2

Switch(eth-B4,C2)# qos dscp 000010

Switch(eth-B4,C2)# int e b1-b3

Switch(eth-B1-B3)# qos dscp 000101

Switch(eth-B1-B3)# int e a2

Switch(eth-A2)# qos dscp 000111

Switch(eth-A2)# show qos port-priority

Port priorities

Port Apply rule | DSCP Priority Radius Override

---- ----------- + ------ ----------- ---------------

A1 No-override | No-override No-override

A2 DSCP | 000111 7 No-override

A3 Priority | No-override No-override

A4 Priority | No-override No-override

B1 DSCP | 000101 5 No-override

B2 DSCP | 000101 5 No-override

B3 DSCP | 000101 5 No-override

B4 DSCP | 000010 1 No-override

C1 No-override | No-override No-override

C2 DSCP | 000010 1 No-override

C3 No-override | No-override No-override

C4 No-override | No-override No-override

HP ProCurve 6200yl Series Advanced Traffic Management Guide
