HP ProCurve 6200yl Series Advanced Traffic Management Guide

8-37
Classifier-Based Software Configuration
Traffic Classes
Figure 8-13. Displaying Policy Resources
Displaying Statistics for a Policy
Only the active redirects (matches, ignores, etc) are displayed when executing
the show statistics command.
HP Switch(config)# show policy resources
Resource usage in Policy Enforcement Engine
| Rules | Rules Used
Slots | Available | ACL | QoS | IDM | VT | Mirror | PBR | Other |
------+-------------+-----+-----+-----+-----+--------+-----+-------|
A | 3014 | 15 | 11 | 0 | 1 | 0 | 0 | 3 |
| Meters | Meters Used
Slots | Available | ACL | QoS | IDM | VT | Mirror | PBR | Other |
------+-------------+-----+-----+-----+-----+--------+-----+-------|
A | 250 | | 5 | 0 | | | | 0 |
| Application |
| Port Ranges | Application Port Ranges Used
Slots | Available | ACL | QoS | IDM | VT | Mirror | PBR | Other |
------+-------------+-----+-----+-----+-----+--------+-----+-------|
A | 14 | 2 | 0 | 0 | | 0 | 0 | 0 |
0 of 8 Policy Engine management resources used.
Key:
ACL = Access Control Lists
QoS = Device & Application Port Priority, QoS Policies, ICMP rate limits
IDM = Identity Driven Management
VT = Virus Throttling blocks
Mirror = Mirror Policies, Remote Intelligent Mirror endpoints
PBR = Policy Based Routing Policies
Other = Management VLAN, DHCP Snooping, ARP Protection, Jumbo IP-MTU,
Transparent Mode.
Resource usage includes resources actually in use, or reserved for future
use by the listed feature. Internal dedicated-purpose resources, such as
port bandwidth limits or VLAN QoS priority, are not included.
Includes hardware resources used by classifier-
based QoS, mirroring, and PBR policies that are
currently applied to interfaces on the switch.
