6-16
Stack Management for the 3500, 3500yl, 6200yl and 6600 Switches
Configuring Stack Management
Figure 6-9. Example of the Stack Management Screen
2. Press
[A] (for Add) to add a Candidate. You will then see this screen listing
the available Candidates:
Figure 6-10. Example of Candidate List in Stack Management Screen
3. Either accept the displayed switch number or enter another available
number. (The range is 0 - 15, with 0 reserved for the Commander.)
4. Use the downarrow key to move the cursor to the MAC Address field,
then type the MAC address of the desired Candidate from the Candidate
list in the lower part of the screen.
5. Do one of the following:
For status descriptions, see the table on page 6-44.
The Commander automatically selects an
available switch number (SN). You have the
option of assigning any other available number.
Candidate List
