HP ProCurve 6200yl Series Advanced Traffic Management Guide

1-29
Static Virtual LANs (VLANs)
Configuring VLANs
For example:
Figure 1-19. Example of “Show VLAN” Listing (GVRP Enabled)
Displaying the VLAN Membership of One or More Ports.
This command shows to which VLAN a port belongs.
Status:
Port-Based: Port-Based, static VLAN
Protocol: Protocol-Based, static VLAN
Dynamic: Port-Based, temporary VLAN learned through
GVRP (Refer to chapter 2, “GVRP” .)
Voice: Indicates whether a (port-based) VLAN is configured as
a voice VLAN. Refer to “Voice VLANs” on page 1-58.
Jumbo: Indicates whether a VLAN is configured for Jumbo
packets. For more on jumbos, refer to the chapter titled “Port
Traffic Controls” in the Management and Configuration Guide
for your switch.
When GVRP is disabled
(the default), Dynamic
VLANs do not exist on the
switch and do not appear
in this listing. (Refer to
chapter 2, “GVRP” .)
HP Switch# show vlans
Status and Counters - VLAN Information
Maximum VLANs to support : 256
Primary VLAN : DEFAULT_VLAN
Management VLAN :
VLAN ID Name | Status Voice Jumbo
------- -------------------- + ---------- ----- -----
1 DEFAULT_VLAN | Port-based No No
10 VLAN_10 | Port-based Yes Yes
15 VLAN_15 | Port-based No No
20 VLAN_20 | Protocol No No
33 VLAN_33 | Dynamic No No
Syntax: show vlan ports < port-list > [detail]
Displays VLAN information for an individual port or a group of
ports, either cumulatively or on a detailed per-port basis.
port-list: Specify a single port number, a range of ports (for
example, a1-a16), or all.
detail: Displays detailed VLAN membership information on a per-
port basis.
