5-68
Quality of Service: Managing Bandwidth More Effectively
Globally-Configured QoS
Figure 5-31. Assigning Priorities to the Specified DSCP Codepoints
3. Assign the DSCP policies to the selected source-ports and display the
result.
HP Switch(config)# qos dscp-map 2 priority 7
HP Switch(config)# qos dscp-map 3 priority 5
HP Switch(config)# show qos dscp-map
DSCP -> 802.p priority mappings
NOTE: 'qos type-of-service diff-services' must be configured
before DSCP is honored on inbound traffic.
DSCP CodePoint DSCP Value 802.1p tag DSCP Policy name
-------------- ---------- ----------- ---------------------------
000000 0 0 cs0
000001 1 No-override
000010 2 7
000011 3 5
000100 4 No-override
000101 5 No-override
000110 6 No-override
000111 7 No-override
001000 8 1 cs1
001001 9 No-override
001010 10 No-override af11
001011 11 No-override
001100 12 No-override af12
001101 13 No-override
001110 14 No-override af13
001111 15 No-override
010000 16 2 cs2
010001 17 No-override
. . .
. . .
. . .
DSCP Policies
Configured in this Step
