HP ProDesk 490 G1 Quickspecs

Intel HD Graphics
VGA Controller Integrated
DisplayPort Multimode capable; supports HDCP, Display Port Audio (2 streams), HBR2 link rates and Multi-Stream
Technology for a maximum of 2 displays (including the integrated panel)
Bus Type N/A
RAMDAC N/A
Memory Intel graphics do not have dedicated memory but utilizes some of the computer's system memory
The amount of memory used for graphics depending on the amount of system memory installed,
BIOS settings, operating system, and system load. 32 MB is pre-allocated for graphics use at system
boot time. Additional memory can be allocated at boot time by the BIOS for PAVP (Protected Audio
Video Playback) support for playback of protected video content.
Additional memory is allocated for graphics as needed using Intel's Dynamic Video Memory
Technology (DVMT), to provide an optimal balance between graphics and system memory use.
Maximum Graphics Memory Microsoft Windows 7 Windows 8.1
Up to 1.7GB Up to 1.8GB
NOTE: the actual amount of maximum graphics memory can be less than the amounts listed above
depending upon your computer's configuration.
Maximum Color Depth 32 bits/pixel
Graphics/Video API Support 4th Generation Core processors:
The Processor Graphics contains a refresh of the seventh generation graphics core enabling
substantial gains in performance and lower power consumption. Up to 16 EU support.
Next Generation Intel Clear Video Technology HD Support is a collection of video playback and
enhancement features that improve the end user's viewing experience
Encode/transcode HD content
Playback of high definition content including Blu-ray Disc
Superior image quality with sharper, more colorful images
DirectX Video Acceleration (DXVA) support for accelerating video processing
Full AVC/VC1/MPEG2 HW Decode
Advanced Scheduler 2.0, 1.0
Windows 7, Windows 8.1, Linux OS Support
DirectX 11.1
OpenGL 4.0
Open CL 1.2
Supported Display Resolutions and Refresh Rates
NOTE: other resolutions may be available but are not recommended as they may not have been tested and qualified by HP
QuickSpecs
HP ProDesk 490 G1 Microtower Business PC
Technical Specifications - Graphics
DA - 14695 Worldwide — Version 2 — November 8, 2013 Page 15

HP ProDesk 490 G1 Specifications

General

Tcase	72.72 °C
Bus type	DMI2
Stepping	C0
Processor cache	8 MB
Processor cores	4
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-4700 Desktop series
Processor socket	LGA 1150 (Socket H3)
Processor threads	8
Processor codename	Haswell
Processor frequency	3.4 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.9 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	84 W
Number of processors installed	1
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3-SDRAM
Memory voltage supported by processor	1.5 V
Memory clock speeds supported by processor	1333, 1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	32 GB
Memory slots	4x DIMM
Internal memory	16 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Maximum internal memory	- GB
HDD size	3.5 \
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Total storage capacity	1000 GB
Intel segment tagging	Enterprise, Small Business
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
On-board graphics card ID	0x412
Discrete graphics card model	NVIDIA® GeForce® GT 630
On-board graphics card model	Intel® HD Graphics 4600
Discrete graphics card memory	2048 GB
Discrete graphics memory type	GDDR3
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	2 GB
On-board graphics card OpenGL version	4.3
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	11.2/12
On-board graphics card dynamic frequency (max)	1200 MHz
Number of displays supported (on-board graphics)	3
Bundled software	HP Client Security\\r HP Trust Circles Standard\\r HP Wireless HotSpot\\r HP PageLift\\r HP Recovery Manager\\r HP Support Assistant\\r HP ePrint\\r CyberLink PowerDVD\\r CyberLink Power2Go\\r Buy Office
Recovery operating system	Windows 8.1 Pro
Operating system installed	Windows 7 Professional
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
HDMI ports quantity	0
PS/2 ports quantity	2
USB 2.0 ports quantity	6
Chassis type	Micro Tower
Product color	Black
Country of origin	China
Audio system	Realtek ALC221
Product type	PC
Motherboard chipset	Intel® H87
Scalability	1S
Processor code	SR149
Processor ARK ID	75122
Intel TSX-NI version	0.00
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal solution specification	PCG 2013D
Intel Identity Protection Technology version	1.00
Power supply	300 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	402 mm
Width	182.8 mm
Height	357 mm
Weight	7140 g
