System Memory Support
The HP ProDesk 490 G1 Business PC supports the 4th generation Intel® Core™ processor family. Based on a new PC micro-architecture,
the processor is designed for a two-chip platform consisting of a processor and Platform Controller Hub (PCH). Unlike previous
generations, the 4th generation Intel® Core™ processor includes an Integrated Memory Controller (IMC). The IMC supports DDR3/DDR3L
protocols with two independent, 64-bit wide channels each accessing one or two DIMMs.
Two channels of non-ECC DDR3/DDR3L unbuffered dual in-line memory modules (UDIMM) or DDR3/DDR3L unbuffered small
outline dual in-line memory modules (SO-DIMM) with a maximum of two DIMMs per channel
Single-channel and dual-channel memory organization modes
Data burst length of eight for all memory organization modes
Memory data transfer rates of up to 1600 MT/s; actual supported data transfer rate determined by the configured processor.
64-bit wide channels
DDR3/DDR3L system memory I/O voltage of 1.5V
Theoretical maximum memory bandwidth of:
21.3 GB/s in dual-channel mode assuming 1333 MT/s
25.6 GB/s in dual-channel mode assuming 1600 MT/s
Platform Memory Support
The Microtower platform supports up to four (4) industry-standard DDR3-SDRAM DIMMs.
CAUTION:
You must shut down the computer and disconnect the power cord before adding or removing memory modules. Regardless
of the power-on state, voltage is always supplied to the memory modules as long as the computer is plugged in to an active AC outlet.
Adding or removing memory modules while voltage is present may cause irreparable damage to the memory modules or system board.
NOTE:
For systems configured with more than 3 GB of memory and a 32-bit operating system, all memory may not be available due to
system resource requirements. Addressing memory above 4 GB requires a 64-bit operating system.
QuickSpecs
HP ProDesk 490 G1 Microtower Business PC
Technical Specifications – Memory
DA - 14695 Worldwide — Version 2 — November 8, 2013
Page 34

Other manuals for HP ProDesk 490 G1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP ProDesk 490 G1 and is the answer not in the manual?

HP ProDesk 490 G1 Specifications

General IconGeneral
Tcase72.72 °C
Bus typeDMI2
SteppingC0
Processor cache8 MB
Processor cores4
System bus rate5 GT/s
Processor familyIntel® Core™ i7
Processor seriesIntel Core i7-4700 Desktop series
Processor socketLGA 1150 (Socket H3)
Processor threads8
Processor codenameHaswell
Processor frequency3.4 GHz
Processor cache typeSmart Cache
Processor lithography22 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version3.0
Processor boost frequency3.9 GHz
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)84 W
Number of processors installed1
Maximum number of PCI Express lanes16
Memory types supported by processorDDR3-SDRAM
Memory voltage supported by processor1.5 V
Memory clock speeds supported by processor1333, 1600 MHz
Memory bandwidth supported by processor (max)25.6 GB/s
Maximum internal memory supported by processor32 GB
Memory slots4x DIMM
Internal memory16 GB
Memory channelsDual-channel
Memory clock speed1600 MHz
Maximum internal memory- GB
HDD size3.5 \
HDD speed7200 RPM
HDD interfaceSATA
Storage mediaHDD
Optical drive typeDVD Super Multi
Card reader integratedYes
Total storage capacity1000 GB
Intel segment taggingEnterprise, Small Business
Intel® Virtualization Technology (Intel® VT)VT-d, VT-x
On-board graphics card ID0x412
Discrete graphics card modelNVIDIA® GeForce® GT 630
On-board graphics card modelIntel® HD Graphics 4600
Discrete graphics card memory2048 GB
Discrete graphics memory typeGDDR3
On-board graphics card familyIntel® HD Graphics
Maximum on-board graphics card memory2 GB
On-board graphics card OpenGL version4.3
On-board graphics card base frequency350 MHz
On-board graphics card DirectX version11.2/12
On-board graphics card dynamic frequency (max)1200 MHz
Number of displays supported (on-board graphics)3
Bundled softwareHP Client Security\\r HP Trust Circles Standard\\r HP Wireless HotSpot\\r HP PageLift\\r HP Recovery Manager\\r HP Support Assistant\\r HP ePrint\\r CyberLink PowerDVD\\r CyberLink Power2Go\\r Buy Office
Recovery operating systemWindows 8.1 Pro
Operating system installedWindows 7 Professional
Cabling technology10/100/1000Base-T(X)
Ethernet LAN data rates10, 100, 1000 Mbit/s
HDMI ports quantity0
PS/2 ports quantity2
USB 2.0 ports quantity6
Chassis typeMicro Tower
Product colorBlack
Country of originChina
Audio systemRealtek ALC221
Product typePC
Motherboard chipsetIntel® H87
Scalability1S
Processor codeSR149
Processor ARK ID75122
Intel TSX-NI version0.00
Processor package size37.5 x 37.5 mm
Supported instruction setsAVX 2.0, SSE4.1, SSE4.2
Thermal solution specificationPCG 2013D
Intel Identity Protection Technology version1.00
Power supply300 W
Sustainability certificatesENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth402 mm
Width182.8 mm
Height357 mm
Weight7140 g
