HP ProDesk 490 G1 Quickspecs

Non-operating vibration Starting at 5 Hz, vary the frequency of vibration from 5 to 500 Hz
and back to 5 Hz at a Logarithmic sweep rate of 1 octave per
minute.
Drop (out of box) 26 in (66 cm) on carpet, six-drop sequence
Drop (in box) 29.93 in (76 cm) on concrete, 16-drop sequence
Approvals CUL, ICES-003 Class B, FCC, CE Mark,TUV GS, VCCI, BSMI, C-Tick, KC
Ergonomic compliance ANSI HFS 100, ISO 9241-4, and TUVGS
HP USB Smart Card (CCID) Keyboard
Key Benefits:
Protects against unauthorized access with smart card technology
Delivers even greater security when combined with a HP ProtectTools smart card and the HP
ProtectTools Security Software
Combination of username and password or pin with a smart card or security token
Secures online transactions using digital signatures and certificates
Conforms to industry standards for ease of setup and use
Delivers long product life and quiet operation with high-impact materials and lubricated keys
Spill drain feature
Physical Characteristics
Keys 104, 105, 106, 107, 109 layout
(depending upon country
Form factor USB basic smart card keyboard
Colors Carbonite/Silver
Dimensions
(H x W x D)
18.2 x 6.3 x 1.3 in (46.3 x 16.1 x 3.3 cm)
Weight 2 lb (0.9 kg) minimum
Electrical
Operating voltage + 5VDC ± 5%
Power consumption 100-mA maximum (with four LEDs ON)
System interface USB Type A plug connector
ESD CE level 4, 15-kV air discharge
EMI - RFI Conforms to FCC rules for a Class B computing device
Microsoft PC 99 - 2001 Functionally compliant
Mechanical
Languages 30+ available
Keycaps Standard design
Switch actuation 55 g nominal peak force with tactile feedback
Switch life 20 million keystrokes
(using Hasco modified tester)
Switch type Contamination-resistant membrane
Key-leveling mechanisms For all double-wide and greater-length keys
Cable length 6 ft (1.8 m)
Microsoft PC 99 - 2001 Mechanically compliant
Acoustics 43-dBA maximum sound pressure level
Operating temperature 50° to 122° F (10° to 50° C)
QuickSpecs
HP ProDesk 490 G1 Microtower Business PC
Technical Specifications – Keyboards and Pointing Devices
DA - 14695 Worldwide — Version 2 — November 8, 2013 Page 41

HP ProDesk 490 G1 Specifications

General

Tcase	72.72 °C
Bus type	DMI2
Stepping	C0
Processor cache	8 MB
Processor cores	4
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-4700 Desktop series
Processor socket	LGA 1150 (Socket H3)
Processor threads	8
Processor codename	Haswell
Processor frequency	3.4 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.9 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	84 W
Number of processors installed	1
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3-SDRAM
Memory voltage supported by processor	1.5 V
Memory clock speeds supported by processor	1333, 1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	32 GB
Memory slots	4x DIMM
Internal memory	16 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Maximum internal memory	- GB
HDD size	3.5 \
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Total storage capacity	1000 GB
Intel segment tagging	Enterprise, Small Business
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
On-board graphics card ID	0x412
Discrete graphics card model	NVIDIA® GeForce® GT 630
On-board graphics card model	Intel® HD Graphics 4600
Discrete graphics card memory	2048 GB
Discrete graphics memory type	GDDR3
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	2 GB
On-board graphics card OpenGL version	4.3
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	11.2/12
On-board graphics card dynamic frequency (max)	1200 MHz
Number of displays supported (on-board graphics)	3
Bundled software	HP Client Security\\r HP Trust Circles Standard\\r HP Wireless HotSpot\\r HP PageLift\\r HP Recovery Manager\\r HP Support Assistant\\r HP ePrint\\r CyberLink PowerDVD\\r CyberLink Power2Go\\r Buy Office
Recovery operating system	Windows 8.1 Pro
Operating system installed	Windows 7 Professional
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
HDMI ports quantity	0
PS/2 ports quantity	2
USB 2.0 ports quantity	6
Chassis type	Micro Tower
Product color	Black
Country of origin	China
Audio system	Realtek ALC221
Product type	PC
Motherboard chipset	Intel® H87
Scalability	1S
Processor code	SR149
Processor ARK ID	75122
Intel TSX-NI version	0.00
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal solution specification	PCG 2013D
Intel Identity Protection Technology version	1.00
Power supply	300 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	402 mm
Width	182.8 mm
Height	357 mm
Weight	7140 g
