HP ProDesk 600 G2 User Manual

Rear panel components
1 PS/2 Mouse Connector (green) 7 PS/2 Keyboard Connector (purple)
2
Serial Connector 8 DisplayPort Monitor Connectors
3
RJ-45 Network Connector 9 VGA Monitor Connector
4
USB 2.0 Ports with Wake from S4/S5 feature
(black)
10 USB 3.0 Ports (blue)
5
Line-In Audio Connector (blue) 11 Line-Out Connector for powered audio
devices (green)
6 Power Cord Connector
NOTE: An optional second serial port and an optional parallel port are available from HP.
If using a USB keyboard, HP recommends connecting the keyboard to one of the USB 2.0 ports with the wake from S4/S5
feature. The wake from S4/S5 feature is also supported on the PS/2 connectors if enabled in BIOS F10 Setup.
When a device is plugged into the blue Line-In Audio Connector, a dialog box will pop up asking if you want to use the
connector for a line-in device or a microphone. You can reconfigure the connector at any time by double-clicking the Audio
Manager icon in the Windows taskbar.
When a graphics card is installed in one of the system board slots, the video connectors on the graphics card and the
integrated graphics on the system board may be used at the same time. However, for such a configuration, only the display
connected to the discrete graphics card will display POST messages.
The system board graphics can be disabled by changing settings in Computer Setup.
Rear panel components 3

HP ProDesk 600 G2 Specifications

General

Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	2133 MHz
Internal memory type	DDR4-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	1 x 4 GB
SSD capacity	128 GB
SSD interface	SATA
Storage media	SSD
Optical drive type	No
Number of SSDs installed	1
Product type	Mini PC
Motherboard chipset	Intel Q150
On-board graphics card	Yes
On-board graphics card ID	0x1912
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 530
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.7 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1050 MHz
Number of displays supported (on-board graphics)	3
Wi-Fi standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Headphone outputs	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
Power supply	65 W
Chassis type	Desktop
Product color	Black
Country of origin	China
Placement supported	Horizontal/Vertical
Tcase	65 °C
Bus type	DMI3
Stepping	S0
Processor cache	3 MB
Processor model	i3-6100
System bus rate	8 GT/s
Processor family	Intel® Core™ i3
Processor series	Intel Core i3-6100 series
Processor socket	LGA 1151 (Socket H4)
Processor threads	4
Processor codename	Skylake
Processor frequency	3.7 GHz
Processor cache type	L3
Processor lithography	14 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor operating modes	64-bit
PCI Express configurations	1x16, 1x8+2x4, 2x8
Thermal Design Power (TDP)	51 W
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3L-SDRAM, DDR4-SDRAM
Memory voltage supported by processor	1.35 V
Memory clock speeds supported by processor	1333, 1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Maximum internal memory supported by processor	64 GB
Sustainability certificates	ENERGY STAR
Operating system installed	Windows 7 Professional
Scalability	1S
Processor code	SR2HG
Processor ARK ID	90729
Processor package size	37.5 x 37.5 mm
Supported instruction sets	SSE4.1, SSE4.2
Thermal solution specification	PCG 2015C
Intel Secure Key Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00
Intel segment tagging	Enterprise, Small Business

Weight and Dimensions

Depth	34 mm
Width	175 mm
Height	177 mm
Weight	1300 g
