HP ProDisplay P19A Specification

Arsenic-Free Display
Glass
4
Yes
Mercury-Free Display
Backlighting
Yes
Low Halogen
5
Yes
Environmental Data Eco-Label Certifications
& declarations
This product has received or is in the process of being certified to the following
approvals and may be labeled with one or more of these marks:
IT ECO declaration
US ENERGY STAR®
TCO 06
EPEAT® Gold where HP registers Commercial Display products. See
http://www.epeat.net for registration status in your country US Federal
Energy Management Program (FEMP)
Energy Consumption
(in accordance with US
Energy Star® test
method) 115VAC, 60Hz 230VAC, 50Hz 100VAC, 60Hz
Normal Operation 15.12 W 14.92 W 15.18 W
Sleep 0.24 W 0.31 W 0.24 W
Off 0.09 W 0.14 W 0.09 W
Heat Dissipation * 115VAC, 60Hz 230VAC, 50Hz 100VAC, 60Hz
Normal Operation 52 BTU/hr 51 BTU/hr 52 BTU/hr
Sleep 0.8 BTU/hr 1 BTU/hr 0.8 BTU/hr
Off 0.3 BTU/hr 0.4 BTU/hr 0.3 BTU/hr
* Heat dissipation is calculated based on the measured watts, assuming the service level is attained for one
hour.
Additional Information This product is in compliance with the Restrictions of Hazardous
Substances (RoHS) directive - 2002/95/EC.
This HP product is designed to comply with the Waste Electrical and
Electronic Equipment (WEEE) Directive - 2002/96/EC.
This product is in compliance with California Proposition 65 (State of
California; Safe Drinking Water and Toxic Enforcement Act of 1986).
This product is in compliance with the IEEE 1680 (EPEAT) standard at the
Gold level, see: www.epeat.net
Plastics parts weighing over 25 grams used in the product are marked per
ISO 11469 and ISO1043.
This product contains 16.2 % post-consumer recycled plastic (by wt.)
This product is 97.5 % recycle-able when properly disposed of at end of
life.
Packaging Materials External: PAPER/Corrugated 808 g
Internal: PLASTIC/EPS (Expanded
Polystyrene)
328 g
PLASTIC/EPE-Expanded
Polyethylene
28 g
QuickSpecs
HP ProDisplay P19A 19-inch LED Backlit Monitor
Technical Specifications
DA - 14553 North America — Version 4 — November 12, 2013 Page 5

HP ProDisplay P19A Specifications

General

3D	No
HD type	SXGA
Panel type	TN
Pixel pitch	0.294 x 0.294 mm
Display diagonal	19 \
Display resolution	1280 x 1024 pixels
Display technology	LED
Native aspect ratio	5:4
Vertical scan range	50 - 76 Hz
Horizontal scan range	30 - 83 kHz
Viewable size, vertical	301 mm
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	1000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	376.3 mm
Viewing angle, horizontal	170 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 960
On/off switch	Yes
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	25 W
Power consumption (standby)	0.5 W
Power consumption (typical)	1 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	EPEAT Gold, ENERGY STAR
Product color	Black
Country of origin	China
Market positioning	-
HDMI ports quantity	0
Tilt angle range	-5 - 25 °
Number of OSD languages	10
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, DUT, ENG, ESP, FRE, ITA, JPN, POR

Weight and Dimensions

Depth (with stand)	206.4 mm
Height (with stand)	418.2 mm
Depth (without stand)	57.5 mm
Width (without stand)	414 mm
Height (without stand)	347 mm
Weight (without stand)	3500 g
