HP ProLiant BL30p

Full featured web-based and scriptable command line (CLI) interfaces, password protected multi-level
user accounts, Telnet, SNMP, BootP client, port mirroring, port-based VLANs and VLAN tagging,
EtherChannel compatible multi-port trunking, network time protocol, spanning tree protocol,
broadcast/multicast storm control, flow control, human readable/writeable configuration file, TFTP
client, IP address security restrictions, auto-MDI/MDIX, auto-negotiation and auto-sensing of speed and
duplex mode, and more.
ProLiant BL p-Class
ProLiant BL p-ClassProLiant BL p-Class
ProLiant BL p-Class
Storage Connectivity Kit
Storage Connectivity KitStorage Connectivity Kit
Storage Connectivity Kit
Option
OptionOption
Option
(supports a pair of two
CGESM or GbE2 switches)
The Storage Connectivity Kit (option) is required for Fibre Channel signal pass-through when using the
CGESM or a GbE2 Interconnect Switch Kit. Both Ethernet cable consolidation and Fibre Channel
connectivity is possible using a single interconnect option. Order one Storage Connectivity Kit per server
blade enclosure for Fibre Channel pass through of HP ProLiant BL20p and HP ProLiant BL30p server
blades series.
The Storage Connectivity Kit includes two OctalFC Interconnect Modules that provide sixteen open
transceiver cages for the pluggable small form factor transceivers that come with each HP ProLiant
BL30p Dual-Port Fibre Channel Adapter (option) and each HP ProLiant BL20p Dual Port Fibre Channel
Adapter. The Storage Connectivity Kit supports up to eight HP ProLiant BL20p server blade series, up to
sixteen HP ProLiant BL30p server blades series or combinations thereof.
ProLiant BL p-Class
ProLiant BL p-ClassProLiant BL p-Class
ProLiant BL p-Class
RJ-45 Patch Panel
RJ-45 Patch PanelRJ-45 Patch Panel
RJ-45 Patch Panel
(A pair of patch panels
provided per kit)
(Each server blade
enclosure requires a pair
of interconnects - patch
panels or interconnect
switches)
6U (10.5-inch), plugs into HP BladeSystem p-Class server blade enclosures.
Passes through Ethernet NIC signals, from all installed server blades, individually out as RJ-45
connections.
Supports Gigabit Ethernet network adapters.
16 RJ-45 connectors on the back of each RJ-45 Patch Panel (32 RJ-45 connections per server blade
enclosure).
The benefits to the RJ-45 Patch Panel are that it:
- Allows the customer to connect signals to their own LAN infrastructure components.
- Provides very economical option enabling the lowest cost blade solution.
- Is completely passive and requires no software or management.
ProLiant BL p-Class RJ-45
ProLiant BL p-Class RJ-45ProLiant BL p-Class RJ-45
ProLiant BL p-Class RJ-45
Patch Panel 2
Patch Panel 2 Patch Panel 2
Patch Panel 2 (with Fibre
Channel pass through)
(A pair of patch panels
provided per kit)
(Each server blade
enclosure requires a pair
of interconnects - patch
panels or interconnect
switches)
NOTE:
NOTE: NOTE:
NOTE: Either Patch Panel
2 or a Switch Interconnect
Kit is required for SAN
connectivity with HP
ProLiant BL20p server
blade series and HP
ProLiant BL30p server
blades series.
6U (10.5-inch), plugs into HP BladeSystem p-Class server blade enclosures
Passes through Ethernet NIC signals, from all installed server blades, individually out as RJ-45
connections.
Supports Gigabit Ethernet network adapters.
16 RJ-45 connectors on the back of each RJ-45 Patch Panel 2 (32 RJ-45 connections per server blade
enclosure).
Passes through Fibre Channel signals, from all installed HP ProLiant BL20p and HP ProLiant BL30p
server blades series, individually out through small form factor pluggable (SPF) transceiver cages.
Supports 2 Gb/s Fibre Channel signals and backward compatible with existing 1 Gb/s Fibre Channel
equipment.
8 Fibre Channel small form factor pluggable (SPF) transceiver cages on the front of each Patch Panel 2
(16 Fibre Channel SPF transceiver cages per server blade enclosure).
The benefits to the RJ-45 Patch Panel 2 are that it:
- Allows the customer to connect signals to their own LAN and SAN infrastructure components.
- Provides a very economical option enabling the lowest cost blade solution.
- Is completely passive and requires no software or management.
- Electrically isolates the Ethernet and Fibre Channel signals from each other.
