Fiber Channel on the HP
Fiber Channel on the HPFiber Channel on the HP
Fiber Channel on the HP
ProLiant BL30p server
ProLiant BL30p serverProLiant BL30p server
ProLiant BL30p server
blade
bladeblade
blade
The following items are needed to connect the HP ProLiant BL30p server blade to a SAN via Fibre
Channel:
1. HP ProLiant BL30p server blade with Dual-Port Fibre Channel Adapter (option) installed
The Dual-Port Fibre Channel Adapter option 354054-B21 is compatible with the HP ProLiant
BL30p server blade (not compatible with HP ProLiant BL20p server blades series)
Two ports on each configured blade provide redundant Fibre Channel connections
Supports up to 2 Gb/s Fibre Channel equipment
Based on the QLogic ISP2312 chipset
Kit includes two small form factor pluggable transceivers with LC connectors for installation into
the interconnect option kit (see 2A and 2B below)
AND
ANDAND
AND
2A. RJ-45 Patch Panel 2 (with Fibre Channel pass through) interconnect option
Enables pass through of both Ethernet and Fibre Channel signals
Ethernet signals exit the rear of the RJ-45 Patch Panel 2 interconnects
Fibre Channel signals exit the front of the RJ-5 Patch Panel 2 interconnects
8 Fibre Channel small form factor pluggable (SPF) transceiver cages on the front of each
Patch Panel 2 interconnect (16 Fibre Channel SPF transceiver cages per server blade
enclosure)
SPF transceivers are included with the BL30p Dual-Port Fibre Channel Adapter kit (option)
OR
OROR
OR
2B. C-GbE2 or F-GbE2 or CGESM Interconnect Kit plus the Storage Connectivity Kit (option)
Enables Ethernet signal consolidation and pass through of Fibre Channel signals
Both Ethernet and Fibre Channel signals exit the rear of the CGESM or GbE2 Interconnect Switch
(with the Storage Connectivity Kit option)
8 Fibre Channel small form factor pluggable (SPF) transceiver slots on the back of each
Interconnect Switch (16 Fibre Channel SPF transceiver cages per server blade enclosure)
SPF transceivers included with the BL30p Dual-Port Fibre Channel Adapter kit (option)
AND
ANDAND
AND
3. Compatible SAN
Optimized for StorageWorks arrays:
Modular Smart Array 1000
Enterprise Virtual Array 5000 (EVA5000) V2; Enterprise Virtual Array 3000 (EVA3000)
XP48, 128, 512, 1024;
Compatible with select 3rd party SANs. Refer to blade storage website for details:
http://h18000.www1.hp.com/products/servers/proliant-bl/p-class/storage.html
Local I/O Cable
Local I/O CableLocal I/O Cable
Local I/O Cable
No PCI slots, all features integrated
Two (2) USB ports, one (1) video port, one (1) iLO port and one (1) serial port
Two (2) Local I/O cables ship with each server blade enclosure with enhanced backplane components
(281404-B22 and 243564-B22)
NOTE:
NOTE: NOTE:
NOTE:
Tested USB devices (keyboard, mouse, floppy) are listed in options section below.
QuickSpecs
HP ProLiant BL30p Server Blade
HP ProLiant BL30p Server BladeHP ProLiant BL30p Server Blade
HP ProLiant BL30p Server Blade
Standard Features (Server Blade)
DA - 11958 Worldwide — Version 19 — August 15, 2005
Page 9
