HP ProLiant DL320 - Installing the Server into the Rack

34 HP ProLiant DL320 Generation 3 Server User Guide
Installing the server into the rack
To install the server into a rack with square, round, or threaded holes, refer to the
instructions that ship with the rack hardware kit.
If you are installing the server into a telco rack, order the appropriate option kit at
the RackSolutions.com website (http://www.racksolutions.com/hp
). Follow the
server-specific instructions on the website to install the rack brackets.
Use the following information when connecting peripheral cables and power
cords to the server.
WARNING: To reduce the risk of electric shock, fire, or
damage to the equipment, do not plug telephone or
telecommunications connectors into RJ-45 connectors.
Item Description
1 PCI-X expansion slot 2, full-length 64 bit/133 MHz
3.3 V (optional PCI Express slot 1, x8)
2 PCI-X expansion slot 1, low-profile half-length
64 bit/100 MHz 3.3 V
3 Power supply
