HP ProLiant DL320e Setup Guide

Setting up the Gen8 server
Complete the following procedure to set up the Gen8 server that you want to register with Insight
RS.
1. Install the Gen8 server as described in the HP ProLiant Gen8 Server Installation Instructions
for your server model at http://www.hp.com/go/proliantgen8/docs.
2. Connect iLO to the network.
3. Install the system software.
During this process, you can configure hardware settings, install an operating system, and
configure iLO settings. When you configure iLO, record the iLO IP address.
NOTE: If you select the HP Intelligent Provisioning Recommended installation method for the
OS installation, the HP Agentless Management Service is installed. For more information about
the available OS installation methods, see the HP Intelligent Provisioning User Guide.
When AMS is installed, the server name is displayed in HP Insight RS and HP Insight Online,
and can be viewed by HP support and your authorized service provider, reseller/distributor,
and installer. To protect your privacy, do not use sensitive information in the name of the Gen8
server.
4. If you did not use the HP Intelligent Provisioning Recommended installation method for the OS
installation, install the Agentless Management Service.
To download the required files, see Table 2 (page 8).
For more information about AMS, see “Using the Agentless Management Service” (page 35).
5. Install the HP ProLiant iLO 3/4 Channel Interface Driver. iLO uses this driver to communicate
with AMS.
To download the required files, see Table 2 (page 8).
6. Verify that version 1.05 or later of the iLO 4 firmware is installed. HP recommends version
1.10 or later.
For information about installing an iLO firmware update, see Chapter 3, “Configuring iLO”
in the HP iLO 4 User Guide.
7. Configure the SNMP settings on the iLO Management – SNMP Settings page in the iLO web
interface.
1. Start the iLO web interface.
2. Navigate to the Administration→Management page.
3. Enter the following information in the Configure SNMP table:
• Select Agentless Management.
• Enter the value(s) for your environment in the Read Community fields.
• Enter the value(s) for your environment in the Trap Community fields.
• Enter the SNMP Alert Destination(s).
For information about other methods you can use to configure these settings, see the HP iLO
4 Scripting and Command Line Guide.
8. Start the OS on the server. The OS must be running when you register for remote support.
Setting up the Gen8 server 9

HP ProLiant DL320e Specifications

General

Bus type	DMI
Stepping	E1
FSB Parity	No
Processor code	SR0PH
Processor cache	8 MB
Processor cores	4
Processor model	E3-1220V2
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200 v2
Processor socket	LGA 1155 (Socket H2)
Processor codename	Ivy Bridge
Motherboard chipset	Intel® C204
Processor frequency	3.1 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor front side bus	- MHz
Processor boost frequency	3.5 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	1x16+1x4, 1x8+3x4, 2x8+1x4
Supported instruction sets	AVX, SSE4.1, SSE4.2
Thermal Design Power (TDP)	69 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	31
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Dual
Memory clock speeds supported by processor	1333, 1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	32 GB
HDD size	- \
HDD interface	-
Total storage capacity	0 GB
Maximum storage capacity	12 TB
Number of HDDs installed	0
Memory slots	4x DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Graphics card	G200
Graphics card family	Matrox
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
USB 2.0 ports quantity	6
Ethernet LAN (RJ-45) ports	2
PCI Express slots version	3.0
Power supply	350 W
Power requirements	100 - 240 V
Power supply input frequency	50 - 60 Hz
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 9144 m
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Sustainability certificates	ENERGY STAR
Chassis type	Rack (1U)
Processor ARK ID	65734
Intel TSX-NI version	0.00
Intel Identity Protection Technology version	1.00
On-board graphics card model	Not available

Weight and Dimensions

Depth	750 mm
Width	434.6 mm
Height	43.2 mm
