Illustrated parts catalog 10
Item Description
Spare part
number
Customer self
repair
c) 146-GB, SAS, 10,000-rpm* 418399-001 Mandatory
1
d) 146-GB, SAS, 10,000-rpm, 6G* 507283-001 Mandatory
1
e) 146-GB, SAS, 15,000-rpm* 504334-001 Mandatory
1
f) 146-GB, SAS, 15,000-rpm, 6G* 512744-001 Mandatory
1
g) 300-GB, SAS, 10,000-rpm* 493083-001 Mandatory
1
h) 300-GB, SAS, 10,000-rpm, 6G* 507284-001 Mandatory
1
i) 500-GB, SAS, 7,200-rpm, 6G* 508009-001 Mandatory
1
j) 60-GB, SATA, 5,400-rpm* 405419-001 Mandatory
1
k) 120-GB, SATA, 5,400-rpm* 459322-001 Mandatory
1
l) 250-GB, SATA, 5,400-rpm* 460426-001 Mandatory
1
m) 500-GB, SATA, 7,200-rpm* 508035-001 Mandatory
1
n) 60-GB, 3G, SATA, SSD, SFF* 572252-001 Mandatory
1
o) 120-GB, SATA, SSD, SFF* 572253-001 Mandatory
1
Options
20 PCI riser board options — —
a) PCI-X riser board, x16* 535321-001 Optional
2
b) PCIe riser board, x8* 493803-001 Optional
2
c) PCIe riser board, x16* 493802-001 Optional
2
21 Trusted Platform Module* 450168-001 No
3
22 Controller options — —
a) FBWC module, 512-MB* 578882-001 Optional
2
b) FBWC module, 1-GB* 505908-001 Optional
2
c) FBWC capacitor pack* 587324-001 Optional
2
d) BBWC cache module, 256-MB* 462974-001 Optional
2
e) BBWC cache module, 512-MB* 462975-001 Optional
2
f) BBWC battery pack* 462976-001 Optional
2
Miscellaneous
23 Battery, 3.3-V, lithium* 234556-001 Mandatory
1
24 AC power cord* 187335-001 Mandatory
1
Cables
25 Cable kit* 532393-001 Mandatory
1
a) Hard drive data cable or Mini SAS cable (2) — —
b) Hard drive backplane power cable (2) — —
c) PCI power cable — —
