HP ProLiant DL360 Generation 7 (G7)

HP 460W Common Slot Gold Hot Plug Power Supply Kit
Part Number 503296-B21
Input Voltage Range ( V rms ) 100 to 240
Frequency Range (Nominal) ( Hz ) 50/60
Nominal Input Voltage ( Vrms ) 100 120 200 208 220 230 240
Maximum Rated Output Wattage Rating 460 460 460 460 460 460 460
Nominal Input Current ( A rms ) 5.5 4.5 2.6 2.5 2.4 2.3 2.2
Maximum Rated Input Wattage Rating ( Watts ) 526 520 505 505 503 503 503
Maximum Rated VA ( Volt-Amp ) 548 542 527 527 524 524 524
Efficiency ( % ) 87.5 88.5 91 91 91.5 91.5 91.5
Power Factor 0.97
Leakage Current ( mA ) 0.42 0.50 0.83 0.87 0.92 0.96 1.00
Maximum Inrush Current ( A peak ) 30
Maximum Inrush Current duration ( mS ) 20
Maximum British Thermal Unit Rating ( BTU-Hr ) 1794 1773 1725 1725 1715 1715 1715
HP 460W Common Slot Platinum Hot Plug Power Supply Kit
Part Number 593188-B21
Input Voltage Range ( V rms ) 100 to 240
Frequency Range (Nominal) ( Hz ) 50/60
Nominal Input Voltage ( Vrms ) 100 120 200 208 220 230 240
Maximum Rated Output Wattage Rating 460 460 460 460 460 460 460
Nominal Input Current ( A rms ) 5.3 4.3 2.5 2.4 2.3 2.2 2.1
Maximum Rated Input Wattage Rating ( Watts ) 512 505 493 493 492 492 491
Maximum Rated VA ( Volt-Amp ) 526 518 506 506 505 505 504
Efficiency ( % ) 89.8 91.2 93.2 93.3 93.5 93.6 93.6
Power Factor 0.985
Leakage Current ( mA ) 0.42 0.50 0.83 0.87 0.92 0.96 1.00
Maximum Inrush Current ( A peak ) 30
Maximum Inrush Current duration ( mS ) 20
Maximum British Thermal Unit Rating ( BTU-Hr ) 1747 1722 1683 1682 1679 1678 1677
QuickSpecs
HP ProLiant DL360 Generation 7 (G7)
Power Specifications
DA - 13598 North America — Version 56 — March 25, 2013 Page 49
