HP ProLiant DL360 Generation 7 (G7)

HP 750W Common Slot Gold Hot Plug Power Supply Kit
Part Number 512327-B21
Input Voltage Range ( V rms ) 100 to 240
Frequency Range (Nominal) ( Hz ) 50/60
Nominal Input Voltage ( Vrms ) 100 120 200 208 220 230 240
Maximum Rated Output Wattage Rating 750 750 750 750 750 750 750
Nominal Input Current ( A rms ) 8.9 7.4 4.3 4.1 3.9 3.7 3.6
Maximum Rated Input Wattage Rating ( Watts ) 857 847 824 824 820 820 820
Maximum Rated VA ( Volt-Amp ) 894 884 859 854 854 854
Efficiency ( % ) 87.5 88.5 91 91 91.5 91.5 91.5
Power Factor 0.97
Leakage Current ( mA ) 0.42 0.50 0.83 0.87 0.92 0.96 1.00
Maximum Inrush Current ( A peak ) 30
Maximum Inrush Current duration ( mS ) 20
Maximum British Thermal Unit Rating ( BTU-Hr ) 2925 2892 2812 2812 2797 2797 2797
HP 750W Common Slot Platinum Hot Plug Power Supply Kit
Part Number 593831-B21
Input Voltage Range ( V rms ) 100 to 240
Frequency Range (Nominal) ( Hz ) 50/60
Nominal Input Voltage ( Vrms ) 100 120 200 208 220 230 240
Maximum Rated Output Wattage Rating 750 750 750 750 750 750 750
Nominal Input Current ( A rms ) 8.6 7.1 4.2 4.0 3.8 3.6 3.4
Maximum Rated Input Wattage Rating ( Watts ) 841 828 809 808 807 806 805
Maximum Rated VA ( Volt-Amp ) 863 850 830 829 828 827 826
Efficiency ( % ) 89.2 90.6 92.7 92.8 93 93.1 93.2
Power Factor 0.985
Leakage Current ( mA ) 0.42 0.50 0.83 0.87 0.92 0.96 1.00
Maximum Inrush Current ( A peak ) 30
Maximum Inrush Current duration ( mS ) 20
Maximum British Thermal Unit Rating ( BTU-Hr ) 2868 2825 2761 2757 2753 2749 2747
QuickSpecs
HP ProLiant DL360 Generation 7 (G7)
Power Specifications
DA - 13598 North America — Version 56 — March 25, 2013 Page 50
