HP ProLiant DL360 Generation 7 (G7)

HP 1200W Common Slot Silver Hot Plug Power Supply Kit
Part Number 500172-B21
Input Voltage Range ( V rms ) 100 to 240
Frequency Range (Nominal) ( Hz ) 50/60
Nominal Input Voltage ( Vrms ) 100 120 200 208 220 230 240
Maximum Rated Output Wattage Rating 800 900 1200 1200 1200 1200 1200
Nominal Input Current ( A rms ) 9.7 9.0 7.0 6.8 6.4 6.1 5.9
Maximum Rated Input Wattage Rating ( Watts ) 930 1034 1348 1348 1348 1348 1348
Maximum Rated VA ( Volt-Amp ) 970 1079 1406 1406 1406 1406 1406
Efficiency ( % ) 86 87 89 89 89 89 89
Power Factor 0.97
Leakage Current ( mA ) 0.42 0.50 0.83 0.87 0.92 0.96 1.00
Maximum Inrush Current ( A peak ) 30
Maximum Inrush Current duration ( mS ) 20
Maximum British Thermal Unit Rating ( BTU-Hr ) 3174 3530 4600 4600 4600 4600 4600
HP 1200W Common Slot Silver Hot Plug Power Supply Kit
Part Number 437573-B21
Input Voltage Range ( V rms ) 36-72
Frequency Range (Nominal) ( Hz ) DC
Nominal Input Voltage ( Vrms ) 36 48 72
Maximum Rated Output Wattage Rating 1200 1200 1200
Nominal Input Current ( A rms ) 38 28 19
Maximum Rated Input Wattage Rating ( Watts ) 1380 1350 1365
Maximum Rated VA ( Volt-Amp ) 1380 1350 1365
Efficiency ( % ) 87 89 88
Power Factor N/A
Leakage Current ( mA ) N/A
Maximum Inrush Current ( A peak ) 20 25 35
Maximum Inrush Current duration ( mS ) 1 1 3
Maximum British Thermal Unit Rating ( BTU-Hr ) 4713 4610 4662
To review typical system power ratings use the HP Power Advisor which is available via the online tool located at URL:
www.hp.com/go/proliant-energy-efficient or www.hp.com/go/hppoweradvisor
QuickSpecs
HP ProLiant DL360 Generation 7 (G7)
Power Specifications
DA - 13598 North America — Version 56 — March 25, 2013 Page 51
