HP ProLiant DL380 Generation 5 Specification

Power Supply Specification Part number 380622-001
Spare Kit 403781-001
Operational Input Voltage Range
(Vrms)
90 to 264
Frequency Range (Nominal) (Hz) 47 to 63 (50/60)
Nominal Input Voltage (Vrms) 100 120 208 220 230 240
Max Rated Output Wattage Rating 800 850 1000 1000 1000 1000
Nominal Input Current (A rms) 10.0 8.8 5.85 5.5 5.2 4.97
Max Rated Input Wattage Rating
(Watts)
980 1035 1193 1186 1172 1169
Max. Rated VA (Volt-Amp) 1000 1056 1217 1210 1196 1193
Efficiency (%) 81.5 82 84 84 85 85.5
Power Factor 0.98 0.98 0.98 0.98 0.98 0.98
Leakage Current (mA) 0.44 0.52 0.91 0.96 1.00 1.04
Max. Inrush Current (A peak) 30 30 30 30 30 30
Max. Inrush Current duration (mS) 3 3 3 3 3 3
NOTES:
- To review typical system power ratings use the Active Answers Power Calculator which is available via the online tool located at url:
http://h30099.www3.hp.com/configurator/calc/Power%20Calculator%20Catalog.xls
To drill down to calculators:
Click on: "ProLiant Servers"
Click on the Server of interest. Example: DL380 G5
Click on: "Power Calculator" link. (You may need to scroll down to see it)
QuickSpecs
HP ProLiant DL380 Generation 5
Power Specifications
DA - 12477 Worldwide QuickSpecs — Version 1 — 6/26/2006 Page 37

HP ProLiant DL380 Generation 5 Specifications

General

Processor Sockets	2
Chipset	Intel 5000P
Memory Slots	8 DIMM slots
Form Factor	2U Rack
Memory	Up to 64 GB
Storage	8 SFF SAS/SATA hot plug drive bays
RAID Support	HP Smart Array P400i/256MB Controller
Network	2 x NC373i Multifunction Gigabit Network Adapters
Power Supply	Redundant hot plug power supplies
Expansion Slots	6 PCI-Express slots
Operating System Support	Windows Server, Linux, VMware
Processor	Intel Xeon 5400/5200 series
