Common Slot Power
Supply
NOTE: Mixing of power supplies in the same server is not supported. All power supplies inside a server
must be exactly the same model. Mixing Gold, Platinum, and Platinum Plus certified power supplies is not
supported.
HP's Common Slot (CS) power supplies allow for commonality of power supplies across a wide range of
ProLiant and Integrity servers, as well as HP Storage solutions, and are designed to provide the highest
power supply efficiency without degrading system performance. HP CS power supplies are tested by the
Electric Power Research Institute (EPRI) and certified through the ECOS 80 Plus power supply program. HP
CS power supply options provide efficiency ratings of up to 94% (80 Plus Platinum) and are available in
three power output options - 460W, 750W, and 1200W - allowing the customer to "right-size" a power
supply for their specific server configuration. All HP Common Slot power sources are UL, CE Mark
Compliant, hot-plug and support redundant configurations.
NOTE: Mixing of power supplies in the same server is not supported. All power supplies must be of the
same output and efficiency rating. If non-matched power supplies are inserted you will get errors and
operation will fail.
HP CS Platinum Plus power supplies are required when enabling HP's Power Discovery Services. a solution
that creates an automated, energy-aware network between IT systems and facilities. This allows your
company to reclaim millions of dollars in wasted power capacity and downtime costs across data centers.
For more information on HP's Power Discovery Services, go to: www.hp.com/go/ipd .
It is highly recommended that you use the HP Power Advisor in defining the "Right-Size" power supply for
your needs. HP Power Advisor can be accessed at: www.hp.com/go/hppoweradvisor .
NOTE: The 80 PLUS program is a unique forum that unites electric utilities, the computer industry, and
consumers in an effort to bring energy efficient technology solutions to the marketplace. 80 Plus
independently tests power supply efficiency and publicly posts the results on www.80Plus.org .
Redundant Power: Optional (1+ 1) power supplies can be purchased through power supply option kits (see
Power Supplies for part numbers).
NOTE: Power Specification and Technical Content for supported power supplies can be found at:
http://h18000.www1.hp.com/products/quickspecs/14209_div/14209_div.html
System Fans
One of the following
depending on Model
4 Hot-Plug Non-redundant Fans ship standard in 1P Models
1P: 4 fans - non-redundancy
1P: 5 fans - redundancy
6 Hot-plug Redundant Fans ship standard in 2P Models
2P: 5 fans - non-redundancy
2P: 6 fans - redundancy
NOTE: Customers may separately purchase redundant fans with the 667855-B21 option kit. Additional fan
to support redundancy are also included in -B21 processor option kits when upgrading from one processor
to two processor.
Required Cabling For required cabling information, refer to the HP Web site at: www.hp.com/servers/dl380e-gen8 .
QuickSpecs
HP ProLiant DL380e Generation 8 (Gen8)
Standard Features
DA - 14328 Worldwide — Version 27 — December 16, 2013 Page 8

HP ProLiant DL380e Gen8 Specifications

General

Bus type	QPI
Stepping	M1
FSB Parity	No
Scalability	2S
Processor code	SR0LS
Processor cache	10 MB
Processor cores	4
Processor model	E5-2403
System bus rate	6.4 GT/s
Processor series	Intel Xeon E5-2400
Processor socket	LGA 1356 (Socket B2)
Processor codename	Sandy Bridge EN
Motherboard chipset	Intel C600
Processor frequency	1.8 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor package size	45 x 42.5 mm
Processor front side bus	- MHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Supported instruction sets	AVX
Thermal Design Power (TDP)	80 W
Number of processors installed	1
Maximum number of PCI Express lanes	24
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25 GB/s
Maximum internal memory supported by processor	375 GB
Memory slots	12
Internal memory	4 GB
Memory clock speed	1333 MHz
Maximum internal memory	384 GB
Memory layout (slots x size)	1 x 4 GB
HDD size	- \
RAID levels	0, 1, 0+1, 5, 5+0
HDD interface	Serial ATA, Serial Attached SCSI (SAS)
Total storage capacity	0 GB
Maximum storage capacity	- TB
Number of HDDs installed	0
Number of HDDs supported	8
Cabling technology	10/100/1000Base-T(X)
USB 2.0 ports quantity	6
PCI Express slots version	3.0
Power supply	460 W
Redundant power supply (RPS) support	-
Chassis type	Rack (2U)
Processor ARK ID	64615
Intel Identity Protection Technology version	0.00

Weight and Dimensions

Depth	698.5 mm
Width	445.5 mm
Height	87.4 mm
Weight	42990 g
