Hardware options installation 83
To install the component:
1. Unfasten the cable management solution to access the power supply bays.
2. Remove the EMI shield from the power supply bay 2.
3. Remove the protective cover from the connector pins on the power supply.
WARNING: To reduce the risk of electric shock or damage to the equipment, do not connect the
power cord to the power supply until the power supply is installed.
