Memory Installation Example
These memory installation example shows the memory sockets associated with the first processor only. This can be applied toward
the memory sockets associated with the other processor also.
4 RDIMMs per processor
Standard memory: 4x4GB RDIMMs (16GB per processor)
Optional memory: Adding 8x8GB RDIMMs to standard memory (80GB per processor)
Maximum memory: Replacing standard memory with 4x16GB QR RDIMMs and 8x8GB DR RDIMMs (maximum of 128GB per
processor)
Processor memory socket
1 2 3 4 5 6
Standard Memory
4GB
4GB
Optional Memory
4GB 8GB 8GB 4GB 8GB 8GB
Maximum Memory
16GB 32GB 16GB 16GB 32GB 16GB
Processor memory socket
7 8 9 10 11 12
Standard Memory
4GB
4GB
Optional Memory
4GB 8GB 8GB 4GB 8GB 8GB
Maximum Memory
16GB 32GB 16GB 16GB 32GB 16GB
NOTE:
1TB capacity is achieved by loading 1 32GB in center socket and remaining sockets with 16GB DIMMs on every memory channel
on all processors.
The following memory options are available from HP:
Memory
NOTE:
DIMM banks are active only when the corresponding processor socket is
populated.
Registered DIMMs (RDIMMs)
HP 2GB (1x2GB) Dual Rank x8 PC3-10600 (DDR3-1333) Registered CAS-9 Memory Kit
593907-B21
HP 4GB (1x4GB) Single Rank x4 PC3-10600 (DDR3-1333) Registered CAS-9 Memory Kit
593911-B21
HP 4GB (1x4GB) Single Rank x4 PC3L-10600 (DDR3-1333) Registered CAS-9 Low Power
Memory Kit
604500-B21
HP 4GB (1x4GB) Single Rank x4 PC3-12800 (DDR3-1600) Registered CAS-11 Memory Kit
676331-B21
HP 8GB (1x8GB) Single Rank x4 PC3-12800 (DDR3-1600) Registered CAS-11 Memory Kit
676333-B21
HP 8GB (1x8GB) Dual Rank x4 PC3-10600 (DDR3-1333) Registered CAS-9 Memory Kit
593913-B21
HP 8GB (1x8GB) Dual Rank x4 PC3L-10600 (DDR3-1333) Registered CAS-9 Low Power
Memory Kit
604502-B21
HP 16GB (1x16GB) Quad Rank x4 PC3-8500 (DDR3-1066) Registered CAS-7 Memory Kit
593915-B21
HP 16GB (1x16GB) Dual Rank x4 PC3L-10600 (DDR3-1333) Registered CAS-9 LP
Memory Kit
627808-B21
HP 16GB (1x16GB) Dual Rank x4 PC3-12800R (DDR3-1600) Registered CAS-11 Memory
Kit
684066-B21
HP 32GB (1x32GB) Quad Rank x4 PC3L-8500 (DDR3-1066) Registered CAS-7 LP Memory
Kit
627810-B21
Load Reduced DIMMs(LRDIMMs)
QuickSpecs
HP ProLiant DL585 Generation 7 (G7)
Memory
DA - 13642 Worldwide — Version 41 — December 12, 2012
Page 46
