HP ProLiant BL685c G6
BL685c G6
Processor
• Up to four Quad-Core AMD Opteron™ processors
(Shanghai)
Memory
• 32 DIMM Sockets
• PC2-6400 Registered DDR2 (800 MHz)
• 256GB max (with 667 MHz 8GB DIMMs)
Internal Storage
• 2 SFF hot-plug drive bays (SAS or SATA)
• 2 non hot-plug drive bays (SSD only)
• Smart Array P400i controller (512MB cache) with
optional BBWC
• RAID 0/1 support
• Direct-Attached and Shared Storage connect options
Networking
• 2 embedded dual-port Flex-10 10GbE Multifunction
server adapters
Mezzanine Slots
3 PCIe x8 mezzanine expansion slots
Additional Features
• Internal USB 2.0 connector
• Internal SD Card slot
• TPM support
Management
• iLO-2 Standard Blade Edition
• Power Meter, Power Regulator, Power Capping
Density
• 8 server blades in 10U enclosure
• 4 server blades in 6U enclosure
