HP ProLiant Generation ML310 - Page 31

Access Times (typical) Random DVD-ROM < 140 ms, CD-ROM < 125 ms
Full-Stroke DVD-ROM < 250 ms, CD-ROM < 210 ms
Data Transfer Rate
(sustained)
DVD-ROM 21.6 MB/sec. Max.
CD-ROM 6 MB/sec. Max.
Cache Buffer 2 MB
Spin-up Time (typical) less than 10 seconds
MTBF 125,000 Power On Hours (POH)
Ambient Temperature Operating 41° to 122° F (5° to 50° C)
Storage/Transportation -40° to 120° F (-40° to 60° C)
Relative Humidity Operating 10% to 90%
Storage/Transportation 5% to 95%
Drive Dimensions
(HxWxD, maximum)
1.62 x 5.75 x 7.87 in (41.3 x 146 x 200 mm)
HP SC40Ge SAS Host
Bus Adapter with RAID
RAID Support RAID 1 (Mirroring)
RAID 0 (Striping)
Logical Drives
Supported
Up to 2 Logical Volumes
Up to 10 drives total in all RAID volumes
Up to 2 Drives per RAID 1
Up to 8 Drives per RAID 0
Maximum Capacity 576GB (8 x 72GB)
Data Transfer Method 64-bit wide, PCI-X 133 MHz (1 GB/s maximum bandwidth)
Port Transfer Rate 12 Gb/s per x4 Wide SAS Port (4 x 3 Gb/s)
Simultaneous Drive
Transfer Ports
2 x4 Wide SAS Connectors
Protocols 3 Gbps SAS (Serial Attached SCSI)
1.5 Gbps SATA (Serial Advanced Technology Attachment)
External SAS
Connectors
None
Internal SAS
Connectors
2 internal SFF8484 x4 SAS Connectors
Upgradeable Firmware 4MB flashable ROM
QuickSpecs
HP ProLiant ML310 Generation 5
Technical Specifications
DA - 12858 Worldwide QuickSpecs — Version 17 — 6.10.2008 Page 31
