HP ProLiant ML110 Generation 5 - Page 27

16X Max SATA DVD-
ROM Drive
Disk Applicable Disk CD-ROM, CD-XA, CD-DA
(Mode 1, Mode 2, Form 1 and 2)
Photo CD (Single and Multi-session)
CD-R, CD-RW
Mixed Mode (Audio and Data combined)
DVD-ROM
DVD-R/RW, DVD+R/RW
CD-R, CD-RW, DVD-ROM, DVD+R,
DVD+RW
Capacity 4.7 GB (DVD-5)
8.54 GB (DVD-9)
Block Size DVD Media 2,048 bytes
Interface SATA
Access Times (typical) Random <140 ms
Full-Stroke <250 ms
Data Transfer Rate Sustained 8100 to 21600 KB/s (6X to 16X)
Bus Rate 1.5 Gbps
Cache Buffer 128 KB
Start-up Time (typical) < 7 seconds
Stop Time < 4 seconds
Laser Parameters Type Semiconductor Laser GaA1As
Wave Length 780 ± 25 nm
Operating Conditions Temperature 41° to 122° F (5° to 50° C)
Humidity 10% to 90%
Dimensions (HxWxD, maximum) 1.7 x 5.85 x 8.11 in (42.9 x 150 x 195 mm)
Weight 2.64 lb (1.2 kg)
HP 4 Internal Port SAS
Host Bus Adapter
(SAS/SATA HP Model)
SATA Protocol SATA 1.5Gb/s
SATA Ports 4 internal
Port transfer rate 1.5 Gb/s total
Maximum Capacity up to 3.0TB (4 x 750GB Non-Hot Plug SATA HDD)
RAID Levels Supported RAID 1 (Mirroring)
RAID 0 (Striping)
Logical RAID Volumes
Supported
2
Dimensions (excluding
bracket)
6.6 x 2.5 x 0.6 in (16.8 x 6.4 x 1.6 cm)
Disk Drive and
Enclosure Protocol
Support
3 Gbps SAS (Serial Attached SCSI)
1.5 Gbps SATA (Serial Advanced Technology Attachment)
Architecture 64-bit
SAS Connectors 1 internal SFF8484 x4 Wide SAS Connectors
12 Gbps per x4 Wide SAS Port (4 x 3 Gbps)
Data Transfer Method PCI-Express x8 - 2 GB/s maximum bandwidth
PCI Bus Speed PCI-Express x8
QuickSpecs
HP ProLiant ML110 Generation 5
Technical Specifications
DA - 12867 U.S. QuickSpecs — Version 25 — 9-28-2009 Page 27
